10 Continue with the installation:
I
I

Load Balancing/RSL Commands

Load Balancing/RSL commands can be used to create
sophisticated configurations or for troubleshooting. You can
enter them at the server command line or add them to the
appropriate NCF file. The commands are summarized below.

bind

This command creates Load Balancing/RSL groups by
specifying slot parameters of primary and secondary NICs.
Syntax
Example
Default
Messages
(continued)
If you are installing only one NIC, select No to finish
loading and exit.
If you are installing more than one NIC, select Yes to set
up another NIC.
el980lb bind pri_slot sec_slot
where:
pri_slot is the PCI slot number of the primary NIC.
sec_slot is the PCI slot number of a secondary NIC.
el980lb bind 10001 10002
None
For all successfully created groups,
Load Balancing/RSL displays:
Group has been created for Primary Slot
# xxxxx
If a group already exists, Load Balancing/RSL displays:
Load Balancing/RSL group for primary
slot # xxxxx already exists.
If Load Balancing/RSL is unable to create a group for at
least one frame type supported by the NIC, the
following is displayed:
Failed to create a group, probably
boards do not exist.
Error conditions:
No valid primary or secondary NIC.
Primary does not have any bound
protocol stack.
Secondary has a protocol stack bound.
Load Balancing/RSL Commands 51
