Using The 3Com Nic Diagnostics Program; Starting The 3Com Nic Diagnostics Program - 3Com EtherLink 3C985B-SX User Manual

58 C
HAPTER

Using the 3Com NIC Diagnostics Program

The 3Com NIC Diagnostics program, which is installed
when you install the Windows NT driver, provides utilities
for working with the 3Com NICs installed in the server.
The program has these windows:
I
I
I

Starting the 3Com NIC Diagnostics Program

Make sure the 3C985B-SX server NIC and the Windows NT
driver are installed.
1 From the Windows Start menu, select
Settings/Control Panel.
2 Double-click the Network icon.
3 In the Network window, click the Adapters tab.
4 In the Adapters tab, click Properties.
The 3Com Installation dialog box appears
Figure 15 3Com Installation Dialog Box
5 Click Diagnostics.
6 Click OK in response to the warning message
that appears on your screen.
After Windows NT restarts, the General tab of the
3Com NIC Diagnostics program appears.
5: D
IAGNOSTICS AND
General shows configuration setting details for the
3Com NICs installed on the server.
Diagnostics allows you to run diagnostic tests.
Support gives access to diagnostics and support
information, and lets you create a problem report about
the NIC that you can e-mail to 3Com.
T
ROUBLESHOOTING
(Figure 15).
