60
C
HAPTER

Viewing NIC Details

To view the details about NIC configuration settings:
1 Select a NIC from the Network Interface Card list box.
2 Click NIC Details.
The NIC Details window
configuration setting is shown with its current value.
When you are finished viewing NIC details, click OK.
Figure 17 NIC Details Window

Using the Diagnostics Window

From the Diagnostics window, you can run the diagnostic
tests summarized in
Table 4 3Com NIC Diagnostic Tests
Test
NIC self-test These tests check the physical components, circuitry,
Packet tests These tests check the NIC's ability to transfer packets.
5: D
IAGNOSTICS AND
Description
and connectors on the NIC.
T
ROUBLESHOOTING
(Figure
17) appears. Each
Table
4.
