Using Procurve Manager (Pcm) Or Procurve Manager Plus (Pcm) - HP ProCurve 2810 Series Management And Configuration Manual

N o t e
Using ProCurve Manager (PCM) or ProCurve Manager
Plus (PCM+)
ProCurve Manager and ProCurve Manager Plus are designed for installation
on a network management workstation. For this reason, the system require­
ments are different from the system requirements for accessing the switch's
web browser interface from a non-management PC or workstation. For
ProCurve PCM and PCM+ requirements, refer to the information provided
with the software.
This procedure assumes that:
You have installed the recommended web browser on a PC or workstation
■
that serves as your network management station.
■ The networked device you want to access has been assigned an IP address
and (optionally) a DNS name, and has been discovered by PCM or PCM+.
(For more on assigning an IP address, refer to "IP Configuration" on page
8-3.)
To establish a web browser session with ProCurve PCM or PCM+ running, do
the following on the network management station:
1. Make sure the Java
are not, refer to the web browser online Help for specific information on
enabling the Java applets.
2. In the Interconnected Devices listing under Network Manager Home (in the
PCM/PCM+ sidebar), right-click on the model number of the device you
want to access.
3. The web browser interface automatically starts with the Status Overview
window displayed for the selected device, as shown in figure 5-1.
If the Registration window appears, click on the Status tab.
Starting a Web Browser Interface Session with the Switch
TM
applets are enabled for your web browser. If they
Using the Web Browser Interface
5-5
