LLDP (Link-Layer Discovery Protocol)

To standardize device discovery on all ProCurve switches, LLDP has been
implemented while offering limited read-only support for CDP as
documented in this manual. For current information on your switch model,
consult the latest Release Notes (available on the ProCurve Networking web
site). If LLDP has not yet been implemented (or if you are running an older
version of software), consult a previous version of the Management and
Configuration Guide for device discovery details.
Table 12-3. LLDP and Features
Feature
View the switch's LLDP configuration
Enable or disable LLDP on the switch
Change the transmit interval (refresh-interval) for
LLDP packets
Change the holdtime multiplier for LLDP Packets
(holdtime-multiplier x refresh-interval = time-to-live)
Change the delay interval between advertisements
Changing the reinitialization delay interval
Configuring SNMP notification support
Configuring transmit and receive modes
Configuring basic LLDP per-port advertisement
content
LLDP (Link Layer Discovery Protocol): provides a standards-based
method for enabling the switches covered in this guide to advertise themselves
to adjacent devices and to learn about adjacent LLDP devices.
An SNMP utility can progressively discover LLDP devices in a network by:
1. Reading a given device's Neighbors table (in the Management Information
Base, or MIB) to learn about other, neighboring LLDP devices.
2. Using the information learned in step 1 to find and read the neighbor
devices' Neighbors tables to learn about additional devices, and so on.
Configuring for Network Management Applications
LLDP (Link-Layer Discovery Protocol)
Default Menu
n/a
Enabled
30 seconds
4 seconds
2 seconds
2 seconds
Disabled
tx_rx
Enabled
CLI Web
— page 12-32 —
— page 12-28 —
— page 12-35 —
— page 12-28 —
— page 12-36 —
— page 12-37 —
— page 12-38 —
— page 12-39 —
— page 12-40 —
12-25
