85DRV3

1-1.6 Advanced system Power Management, supporting:

• ACPI 1.0B compliant (Advanced Configuration and Power Interface);
• APM V1.2 compliant (Legacy power management);
• ACPI STR mode (Suspend To RAM) , POS (Power On Suspend) and STD
(Suspend to Disk);
• Wake On Modem (External) and Wake On LAN supported by Ring Power
On Control;
• Real time clock (RTC) with date alarm, month alarm, and century field.
• USB wake-up Function;

1-1.7 Multi-I/O Functions:

• PCI EIDE Controller, supporting:
-- 2x Ultra ATA 133/100 / 66 / 33 IDE Connectors supporting up to 4 IDE
devices;
• Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two complete
serial ports or the third dedicated port Infrared-IrDA (HPSIR) and ASK
(Amplitude Shift Keyed) IR.
• Multi-mode parallel Data transfer:
-- Standard mode, ECP and EPP support;
• Floppy Disk connector:
-- One FDD connector with drive swap support;
• Universal Serial Bus Transfer Mode:
-- USB V1.1 compliant;
-- 2 built-in USB connectors and one USB Headers (USB3) which requires one
optional USB cable to provide 2 more optional USB ports;
• PS/2 Keyboard
• PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two complete Serial Ports (COM1 & COM2) on board;

1-1.8 Expansion Slots

• Six PCI bus Master slots;
• One AGP 4x/2X slot;
• One CNR slot (supporting Modem / Audio Riser only);
• Three DDR DIMM slots;
12
