1-2.6 Advanced system Power Management, supporting:

• ACPI 1.0B compliant (Advanced Configuration and Power Interface)
• APM V1.2 compliant (Legacy power management)
• ACPI STR mode (Suspend To RAM) , POS (Power On Suspend) and
STD (Suspend to Disk)
• PS/2 Keyboard & Mouse power on
• Supporting Ring Power Up Control for Wake-on-Modem(external) and
Wake-on-LAN
• Real Time Clock (RTC) with date alarm, month alarm, and century field
• USB wake-up Function;

1-2.7 Multi-I/O Functions:

• PCI EIDE Controller, supporting:
-- 2x Ultra ATA100 / 66 / 33 IDE connectors supporting up to 4 IDE de-
vices
• Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two
complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode parallel Data transfer:
-- Standard mode, ECP and EPP support
• Floppy Disk connector:
-- One FDD connector with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V1.1 compliant;
-- 2 built-in USB connectors and one USB Header (USB2) which
requires an optional USB cable to provide 2 more optional USB ports
• PS/2 Keyboard
• PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two complete Serial Ports (COM1 & COM2) on board

1-2.8 Expansion Slots

• Six PCI bus Master slots
• One AGP 4x/2X slot
• Three DDR DIMM slots
