Installation and Setup Guide
PROMPT
XMIT TO CONFIRM
✱
PRESS TO SKIP
Entd A022-4063
Rcvd A022-4064
5-10
VALID ENTRIES
Confirm
[∗] to continue
Not Confirmed
[∗] to continue
EXPLANATION
13. If "Yes" was entered at the SET TO
CONFIRM? prompt previously (see first
prompt following entry into the •58 Expert
Programming Mode), the display on the left
will appear. Confirm serial and loop numbers
by activating the wireless key.
IMPORTANT:
When confirmed, the key is not active until it is
assigned to a user number (using the assigning
attributes command, attribute "4"). See System
Operation section for procedure.
If the serial number transmitted does not match
the serial number entered, a display similar to the
one shown will appear. If the loop number does
not match, it will also be displayed.
If so, activate the button on the wireless key once
again. If a match is not obtained (i.e., summary
display does not appear), press the [#] key and
then enter the correct serial number.
If the serial number transmitted matches the
serial number entered, the keypad will beep 3
times and will return you to step 8 to enter the
starting zone for the next wireless key.
NOTE: Following the successful enrollment of
each wireless device, remove ONE of the serial
number labels from the device and affix it in the
appropriate column on the ENROLLED
TRANSMITTERS worksheet of the Programming
Form; then enter the other information (zone
number, zone type, loop number, etc.) relevant to
that device.
