FIELD TITLE and DATA ENTRIES
Zone Bypass Limit
*180
0 = unlimited zone bypasses in each partition
1-7 = number of zone bypasses allowed in
each partition
8 = zone bypass disabled (no zones can be
bypassed)
AC and Clock Display Options
*181
0-15 = desired options based on chart at right.
Summer Time Switchover Day
*182
0 = switch on Sunday morning
1= switch on Saturday morning
2 = switch on Friday morning
Date/Time Format
*183
0 = 12-hour time/MMDDYY date
1 = 12-hour time/DDMMYY date
2 = 24-hour time/MMDDYY date
3 = 24-hour time/DDMMYY date
Downloader Suppression Options
*185
0 = no suppression
1 = suppress user code viewing
2 = suppress commands and program
download when armed
3 = suppress user code viewing, commands,
and program download when armed
EXPLANATION
Select the maximum number of zones that can be
bypassed.
Each partition individually uses this entry.
Use the following table to select the desired options
for real-time clock synchronization (50Hz, 60Hz,
Crystal), AC loss display (independent of AC loss
report enabled in *62), and clock display (time
displayed on bottom line of alpha keypads).
X10 NOTE: "X10" (powerline carrier devices) use the
selected AC frequency to communicate with the
control.
Entry AC Freq. Crystal for AC Loss disp Clock disp
0 60Hz clock backup
1 50Hz clock backup
2 60Hz clock
3 50Hz clock
4 60Hz clock backup
5 50Hz clock backup
6 60Hz clock
7 50Hz clock
8 60Hz clock backup
9 50Hz clock backup
#+10 60Hz clock
#+11 50Hz clock
#+12 60Hz clock backup
#+13 50Hz clock backup
#+14 60Hz clock
#+15 50Hz clock
Select the appropriate summer time switchover day.
Select the desired time and date format.
Select the desired options.
Data Field Programming
no no
no no
no no
no no
yes no
yes no
yes no
yes no
no yes
no yes
no yes
no yes
yes yes
yes yes
yes yes
yes yes
4-17
