//*/* FAILURE*/
//TIMEOUT=REDRIVE/* PSF ACTION ON TIMEOUT*/
//MGMTMODE=OUTAVAIL,/* PRINTER MANAGEMENT MODE*/
//DISCINTV=15,/* DISCONNECT INTERVAL IN*/
//*/* SECONDS*/
//IPADDR='xxx.xxx.xxx.xxx'/* IP ADDRESS FOR TCP/IP*/
//PRT1ENDCNTL
Figure 25. Sample PSFPROC procedure
NOTE: To specify a TCP/IP address space name other than the
The IP address is the only required parameter. Other parameters
may be set to facilitate printer sharing as described in "Sharing Line
Matrix Printers on z/OS" on page 97. For a description of the
PRINTDEV statement, which is not given here, see the PSF
System Programming Guide.
IPADDR
Specifies the IP address for the printer or attachment, in dotted-
decimal notation. Do not specify a hostname in place of the dotted-
decimal address.
default, TCPIP, code the following exec statement in the
writer procedure:
//STEP01EXEC PGM=ASPPIEP,REGION=4096K,
PARM=(,,,,tcpip_name)
where tcpip_name is the name of the TCP/IP address
space. If this parameter is not coded, PSF uses the default
name, TCPIP.
Configuration Procedure
95
