Printronix PrintNet P8000 Line User Manual page 196

Chapter 12
Complete Command List
set var <VAR> [<VARIABLE-STRING>]
Example: set var LANDSCAPE 0x1b 0x26 0x6c 0x31 0x4f
Define a new variable to be used in header, trailer, or switch
strings on the PrintNet and call it <variable-string>.
<variable-string> can be a space-separated list of words,
hexadecimal numbers (e.g., 0x04), or references to other
pre-defined variables. It is easiest to make up the
<variable-string> with hexadecimal values, as shown in
the example.
NOTE: One variable counts as one element within header and
set var from default
Set all variable settings back to factory defaults.
set var from stored
Set all current variable settings to the values stored in flash
memory.
196
trailer strings.
Defined variables are referenced in strings by placing a "$"
before the variable name (e.g., set model m1 trailer
$FF).
