Chapter 7
Configuring AS/400 for ASCII using TCP/IP
System: BLDD6
Internet address:
Subnet mask:
Line description:
Line type:
Interface status:
Type of service:
Maximum transmission unit:
Automatic start:
Figure 27. Example of ADDTCPIFC Interface
The following parameters must be specified:
Internet Address
Internet address of the AS/400 LAN printer.
NOTE: Do not use the IP address of the PrintNet.
Subnet Mask
The Subnet Mask for this AS/400 TCP/IP interface (for example,
255.255.255.0).
Line Description
The name assigned to the AS/400 line description as described in
"Developing Line Descriptions With CRTLINETH" on page 101.
NOTE: Each AS/400 LAN printer will have its own line description.
104
9.99.15.188
255.255.255.0
ETHLAN
*Elan
Inactive
*Normal
*Lind
*Yes
