I-Class Mark II Maintenance Manual
1.1
About the Printer
The following drawing highlights the major components of the printer.
Leveling Cam
Printhead Latch
Printhead
Media Sensor
Platen
Media Idler
Media Guide
Power Supply
Ribbon Idler
Option Cards
Main PCB
Drive Gears
Filler Block
Drive Motor
2
Overview
Cover Assembly
Ribbon Take-up Hub
Ribbon Supply Hub
Media Hub
Internal Rewind
Printhead Assembly
Platen Block
Front Panel
