Overview
1.1 About the Printer
The following drawing highlights the user-assessable components of the printer.
Access Cover
Ribbon Supply Hub
Ribbon Take-Up Hub
Media Hub
Front Panel
Printhead Assembly
Fill Block
Internal Rewinder
Printhead
Leveling Cam
Media Sensor
Printhead Latch
Ribbon Idler
Platen
Media Idler
Media Guide
1-2
