Datamax I-Class Mark II Maintenance Manual page 11

I-Class Mark II Maintenance Manual
Advanced Entry Calibration (continued)
Step Action
Use the UP and DOWN Arrow
buttons to set the Gain Number to
00.
F Record the sensor reading as a
Label Value for Gain Number 00 in
a table (32 rows by four columns,
with headings similar to those
shown below.)
Gain Number
Step Action
Use the UP and DOWN Arrow
buttons to increment the Gain
Number by one and then Record
G the Label Value.
Repeat this process for each Gain
Number.
Gain Number
Displayed Message
TRAN SENSOR GAIN
Sample Calibration Table
Label Value
00 252
01
02
...
31
Displayed Message
TRAN SENSOR GAIN
Sample Calibration Table
Label Value
00 252
01 250
02 248
... ...
31 09
Adjustments and Maintenance
This is the Label Value for a gain
00
setting of 00.
(0 - 31)
TOF Value
01 This is the Label Value for a gain
(0 - 31) setting of 01.
TOF Value
7
Comment
Difference Value
Comment
Difference Value
