I-Class Mark II Maintenance Manual
Fault Messages (continued)
Displayed
Description
Message
Consistently low
Reflective Mode sensor readings
Calibration Failed have been
recorded.
Consistently
Reflective Mode high sensor
Faulty Sensor readings have
been recorded.
Solution
Press any key to continue. Retry the STANDARD
CALIBRATION, ensuring that the reflective mark is
inserted facedown during the appropriate step in
the procedure (see Section 2.1.3). If this fails, try
ADVANCED ENTRY (see Section 2.1.4).
If the problem persists, it can be due to one of
following reasons:
1) The reflective marks may not be made of
carbon-based ink.
2) Possible debris in the Media Sensor; clean and
retry calibration (see Section 2.4.3).
3) The Media Sensor may be defective; replace it
(see Section 4.8).
4) The Main Logic PCB may be defective; replace it
(see Section 4.9).
Press any key to continue. Retry the STANDARD
CALIBRATION, ensuring that media is removed
during the appropriate step in the procedure (see
Section 2.1.3).
If the problem persists, it can be due to one of
following reasons:
1) Possible debris in the Media Sensor; clean it
then retry calibration (see Section 2.4.3).
2) The Media Sensor may be defective; replace it
(see Section 4.8).
3) Possible defective Main Logic PCB; replace it
(see Section 4.9).
38
Troubleshooting
LED Status
N/A
RED: ON
GREEN: OFF
