I-Class Mark II Maintenance Manual
NEVER exceed the recommended Printhead Voltage; permanent damage or
shortened service life can result.
WARNING
Printer
Model
I4212e
I4310e
I4606e
Printhead Voltage Adjustment Table
Printhead Resistance
(ohms)
572 - 597
598 - 622
623 - 647
648 - 672
673 - 697
698 - 722
723 - 747
748 - 772
947 – 989
990 – 1030
1031 – 1072
1073 – 1114
1115 – 1156
1157 – 1197
1198 – 1239
1240 – 1281
1530 – 1598
1599 – 1665
1666 – 1733
1734 – 1800
1801 – 1868
1869 – 1935
1936 – 2003
2004 – 2070
17
Adjustments and Maintenance
Printhead Voltage
(+/- 0.1 Volt DC)
22.4
22.9
23.3
23.8
24.2
24.7
25.1
25.5
22.4
22.9
23.4
23.8
24.2
24.7
25.1
25.5
22.4
22.9
23.4
23.8
24.2
24.7
25.1
25.5
