I-Class Mark II Maintenance Manual
Removal and Replacement
3. Rotate the Ribbon Supply Hub until the Pin engages the Notch in the Housing.
Housing
Ribbon
Supply Hub
Nylon
Washer
Notch
Pin
4. Secure the Ribbon Supply Hub to the Housing with the Metal Washer and Screw.
5. Reinstall the Thermal Transfer Assembly; see Section 4.14.
67
