Chapter 8. Web Access and Management

Sending Running Text in a Call

During a videoconference call, you can type and send a text message to the
person(s) with whom you are communicating. The message is displayed as
running text on top of the video image on the far-end screen.
xPoint Standard (S) Ver. 1.5 User Guide
o From Date/To Date – Use these boxes to define a date range for
the recordings that you want to display on the list. Only the
recordings that were saved in the defined range will be displayed
once you click the Search button. You can browse for specific
From/To dates using the two Browse buttons available next to the
text boxes.
The Recording Archive list shows the following details for each saved
recording:
o Name – Name of the recording. You can click the adjacent Rename
button if you want to change the file name.
o Date – Date on which the recording was made and saved.
o Time – Time at which the recording was made and saved.
o Size – Size of the recording file in kilobytes or megabytes.
o Duration – The recording's length.
The currently available disk space size, labeled Free Space, is displayed
above the list.
To delete a recording:
Select the checkbox on the row of the recording's entry, and then click
Delete. You can select more than one recording.
To select the checkboxes of all recordings that are currently displayed,
click Select All.
To clear the checkboxes of all recordings that are currently displayed,
click None.
To type and send a running text message:
1. Start the videoconference call; the Running Text button appears in the
Call View box (available only in the Web interface).
Sending Running Text in a Call
• 75
