Chapter 7. Advanced Settings

Recording and Streaming Settings

You can define the local directory in which recordings should be saved, and also
define the video streaming port parameters.
xPoint Standard (S) Ver. 1.5 User Guide
Figure 29. Multicast Settings Window
2. In the Multicast Settings window, set the following options and
parameters
o Multicast IP Address – IP address and gateway. The IP is dynamic
according to unit's IP. The first subgroup of the IP format
(AAA.BBB.CCC.DDD) is set to 239 according to the standard. You
can change it to any value from 224 to239, and you can also change
the rest of the sub groups (not recommended for multicast
communications).
o Bandwidth – Maximum bandwidth (in Kbps) allowed for outgoing
multicast streams.
o Video Format – The digital encoding format using during the
multicast transmission; by default is set to H.264.
o Video Port – Number of the port through which the video multicast
passes.
o Maximum Video Resolution – Select the required video
resolution from the drop-down list.
o Audio Format – The Audio codec responsible during the
transmission; by default is set to AAC-LD.
o Audio Port – Number of the port through which the audio
multicast passes.
o Maximum Participants – Maximum number of participants
allowed in an IMC session.
o Time to Live – The number of router hops allowed.
o Announcement Rate – SDP announcement rate in seconds.
o Refresh Video Rate – The video image refresh rate in multicast
streams; an interval of 5 seconds is set by default.
3. Select Apply.
To configure the recording and streaming settings:
1. Select Settings>Media; the Recording and Streaming Settings
window appears.
Recording and Streaming Settings
