Chapter 7. Advanced Settings

ISDN Lines Configuration

The ISDN Lines Configuration window enables you to set the phone numbers of
up to 2 lines.
xPoint Standard (S) Ver. 1.5 User Guide
o Available Adapters – Displays the list of ISDN adapters available
for this system. Click on Discover to populate the Available Adapters
list, and select the desired adapter from the list. After you select an
adapter, the Adapter Information, IP address and MAC address of
the adapter are displayed.
o Discover adapters – Select this button to scan for available ISDN
adapters.
o Adapter Information –
IP Address – IP address of the ISDN adapter.
MAC Address – MAC Address of the ISDN adapter.
o Line Indicators – Displays the line status after connecting:
Line 1: ISDN line status for line number 1
Line 2: ISDN line status for line number 2
Line 3: Not available in xPoint
Line 4: Not available in xPoint
3. Select Next to continue to the ISDN Lines Configuration step (see next
section: ISDN Lines
To define the ISDN phone numbers:
1. Enter the appropriate number for each field, without the area or country
code.
Note: depending on the switch type you selected, an additional step may
be required. If you are not sure what numbers to enter, consult your
system administrator.
S
S
Configuration).
ISDN Settings
• 62
