Chapter 3. Configuration Basics
xPoint Standard (S) Ver. 1.5 User Guide
Figure 10. Display Settings Window
To configure the basic display settings:
1. In the Display Settings window, set the following options:
o Display Mode –
Single Mode – Both videoconference parties are displayed on a
single screen.
Dual Mode – Conferences are displayed on two screens. This
option is available only when two screens are connected.
o Keep Aspect Ratio – Select this option to keep the original aspect
ratio on screens that have different aspect ratio.
o Change display settings – see
Chapter 7. Advanced
2. Select Apply.
Note: to simplify the step instructions in the next chapters, the basic
menu access procedure is shortened to the menu path only. For example,
the short instruction "Select Settings> Display" replaces the basic
procedure:
1. Press OK on the remote control; the main menu appears.
2. Using the remote control's joystick, select Settings> Display, and
then press OK; the Display Settings window appears.
Display Adapter Settings
Settings.
Configuring the Display
in
• 24
