Chapter 5. Quick Dialing Methods
Editing Entries in the Personal Address Book
You can edit frequently used numbers already in the personal address book and
save them for repeated use.
Deleting Entries from the Personal Address Book
You can delete and thus manage personal address book entries when they are no
longer in use.
Using the Call Log
Log Entries are automatically logged to the Call Log when an outgoing call is
made or when an incoming call is received. Add Log Entries to the address book,
or delete them from the Call Log.
Using the Call Log via the Remote Control
You can select Call Log using the remote control.
xPoint Standard (S) Ver. 1.5 User Guide
Note: you can also set the dialing method (H.323 or ISDN) and the
bandwidth that you want to use specifically for the contact that you add.
If you choose ISDN, the number to be dialed must be predefined (see
ISDN
Settings).
To edit a contact's details in the personal address book:
1.
In the personal address book, select the entry you want to edit and then
press OK on the remote control.
2.
Select OK in the GUI; the Name/Address bar opens.
3.
Edit the contact name and IP address, and then select Save.
Note: if necessary, you can change the dialing method (H.323 or ISDN)
and bandwidth that are used specifically for the contact that you edit. If
you choose ISDN, the number to be dialed must be predefined (see
Settings).
To delete a contact from the personal address book:
1.
In the address book, select the number you want to delete, select Delete
and then press OK. The following message is displayed: "Are you
sure?"
2.
Select Yes to delete, or No to cancel.
Note: log entries cannot be edited.
Using the Call Log
ISDN
• 38
