Chapter 6
Dome lights

Dome light models

122
Dome lights used in the Telligence nurse call system can have one,
two, or four light sections. Telligence dome light models include:
Table 8: Telligence Dome Light Models
Model Description
HC-CL1-RED One-section dome/zone light
HC-CL2 Infinity Series two-section dome/zone light
HC-CL4 Infinity Series four-section dome/zone light
HC-CL4-SUPV Supervision four-section dome/zone light with buzzer
Notes
• Use the HC-CL4-SUPV dome light for supervision only. The
buzzer is better suited for staff console or annunciator trouble
alerts only.
• To signal dome light alarm conditions, a separate yellow light
behind the top light section of all 2- and 4-section dome lights
illuminates more faintly than nurse call indicator lights.

Corridor lights

Corridor lights are intelligent lights with visual indicators that signal
nurse call types and priorities. Corridor lights, mounted outside
patient or staff rooms in facility hallways, indicate conditions inside
patient or staff rooms.
Two Infinity series dome light models can be used as corridor lights:
• The HC-CL2 Infinity dome/zone light has two light sections. Each
section is programmed to display one of nine possible colors:
blue, red, white, amber, green, pink, cyan, magenta, or yellow.
The top section in a two-section dome light annunciates the
highest nurse call event for the patient or staff room associated
with the light. The bottom dome light section annunciates
registered presence or a nurse call reminder.
• The HC-CL4 Infinity dome/zone light has four light sections,
each of which is programmed to display one of nine possible
colors: blue, red, white, amber, green, pink, cyan, magenta, or
yellow. The top light section in a four-section dome light
annunciates higher priority nurse calls, the second light section
down annunciates lower priority nurse calls, the third light
section down shows any registered presence, and the bottom
light section indicates placement of any nurse call reminder for
the associated patient bed/room or staff room.
The HC-CL4 Infinity dome/zone light appears below.
