Intel Quad-Core Xeon Datasheet page 73

Land Listing
Table 4-2. Land Listing by Land Number
(Sheet 13 of 20)
Pin
Pin Name
No.
F11 D23#
F12 D24#
F13 VSS
F14 D28#
F15 D30#
F16 VSS
F17 D37#
F18 D38#
F19 VSS
F2 GTLREF_ADD_MID
F20 D41#
F21 D43#
F22 VSS
F23 RESERVED
F24 TESTHI07
F25 TESTHI02
F26 TESTHI00
F27 VTT_SEL
F28 BCLK0
F29 RESERVED
F3 BR0#
F30 VTT
F4 VSS
F5 RS1#
F6 RESERVED
F7 VSS
F8 D17#
F9 D18#
G1 BPMb0#
G10 GTLREF_ADD_END
G11 DBI1#
G12 DSTBN1#
G13 D27#
G14 D29#
G15 D31#
G16 D32#
G17 D36#
G18 D35#
G19 DSTBP2#
G2 COMP2
Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
Signal
Direction
Buffer Type
Source Sync Input/Output
Source Sync Input/Output
Power/Other
Source Sync Input/Output
Source Sync Input/Output
Power/Other
Source Sync Input/Output
Source Sync Input/Output
Power/Other
Power/Other Input
Source Sync Input/Output
Source Sync Input/Output
Power/Other
Power/Other Input
Power/Other Input
Power/Other Input
Power/Other Output
Clk Input
Common Clk Input/Output
Power/Other
Power/Other
Common Clk Input
Power/Other
Source Sync Input/Output
Source Sync Input/Output
Power/Other Input/Output
Power/Other Input
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Power/Other Input
Table 4-2. Land Listing by Land Number
(Sheet 14 of 20)
Pin
Pin Name
No.
G20 DSTBN2#
G21 D44#
G22 D47#
G23 RESET#
G24 TESTHI06
G25 TESTHI03
G26 TESTHI05
G27 TESTHI04
G28 BCLK1
G29 BSEL0
G3 BPMb3#
G30 BSEL2
G4 BPMb2#
G5 PECI
G6 RESERVED
G7 DEFER#
G8 BPRI#
G9 D16#
H1 GTLREF_DATA_END
H10 VSS
H11 VSS
H12 VSS
H13 VSS
H14 VSS
H15 DP1#
H16 DP2#
H17 VSS
H18 VSS
H19 VSS
H2 GTLREF_DATA_MID
H20 VSS
H21 VSS
H22 VSS
H23 VSS
H24 VSS
H25 VSS
H26 VSS
H27 VSS
H28 VSS
Signal
Direction
Buffer Type
Source Sync Input/Output
Source Sync Input/Output
Source Sync Input/Output
Common Clk Input
Power/Other Input
Power/Other Input
Power/Other Input
Power/Other Input
Clk Input
CMOS Output
Asynchronous
Common Clk Input/Output
CMOS Output
Asynchronous
Common Clk Output
Power/Other Input/Output
Common Clk Input
Common Clk Input
Source Sync Input/Output
Power/Other Input
Power/Other
Power/Other
Power/Other
Power/Other
Power/Other
Common Clk Input/Output
Common Clk Input/Output
Power/Other
Power/Other
Power/Other
Power/Other Input
Power/Other
Power/Other
Power/Other
Power/Other
Power/Other
Power/Other
Power/Other
Power/Other
Power/Other
