Intermec EasyCoder PM4i User Manual page 137

Allowed interface combinations
Allowed interface combinations (Fingerprint)
Left-hand slot
Double Serial
Double Serial
Double Serial
Double Serial
Serial/Industrial
Serial/Industrial
Serial/Industrial
Serial/Industrial
IEEE 1284
IEEE 1284
IEEE 1284
IEEE 1284
RFID
RFID
RFID
Remarks:
• The left-hand slot is the slot closest to the center section.
• Always start by fitting an interface board in the left-hand slot.
• RS-485 is only supported by "uart2:"
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
Ports
uart2: + uart3:
uart2: + uart3:
uart2: + uart3:
uart2: + uart3:
uart2:
uart2:
uart2:
uart2:
centronics
centronics
centronics
centronics
uart2:
uart2:
uart2:
Appendix C—Interfaces
Right-hand slot
–
IEEE 1284
Double Serial
RFID
–
Serial/Industrial
IEEE 1284
RFID
–
Double Serial
Serial/Industrial
RFID
Double Serial
IEEE 1284
Serial/Industrial
Ports
–
centronics:
uart4: + uart5:
uart4:
–
uart3:
centronics:
uart3:
–
uart2: + uart3:
uart2:
uart2:
uart4: + uart5:
centronics
uart4:
