Recommended Feed Adjustments

The following settings allow printing from the top of the label. Minor
deviations from the recommended values may be required due to various
combinations of media types, roll size, type of media supply device, and
individual differences between printers.
Adjustment 8 dots/mm
type 203.2 dpi (std) 300 dpi (option)
Tear-Off (Straight-through)
Start adjust:
Stop adjust:
Peel-Off (Self-strip)
Start adjust:
Stop adjust:
Cut between labels w. gaps
Start adjust:
Stop adjust:
Cut fix and variable length strip
Start adjust:
Stop adjust:
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
11.81 dots/mm
-100 dots
0 dots
-56 dots
-44 dots
-325 dots
+240 dots
-340 dots
+340 dots
Chapter —Setting Up the Printer
-148 dots
0 dots
-83 dots
-65 dots
-480 dots
+354 dots
-502 dots
+502 dots
Distance Distance
in mm in inches
12.5 0.49
0
7 0.28
5.5 0.22
40.6
30.0 1.18
42.5 1.67
42.5 1.67
0
1.6
