Chapter —Installation
Front View
At the front of the printer are the display window, the control lamps, and
the keyboard. These features allow the operator to control and set up the
printer manually.
The printed labels, tickets, or tags are presented at the front of the print
mechanism, which is covered by a door.
Indicator lamps
Display window
Print button
Keyboard
Side door
Print mechanism
Front door
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
