Appendix B—Media Specifications

Media Roll Size

Core

Diameters (A): 38-40 mm (1.5 inches) or 76.2 mm (3 inches)
Width:
The media must be wound up on the core in such a way that
the printer can pull the end free.

Roll

Max. diameter (B):
Max. width (C):
Min. width (standard) (C):
Min. width (fan-fold guides) (C):
The maximum recommended media thickness is 175µm (7 mils) with
the standard printhead or 220µm (8.7 mils) with a special printhead.
Thicker media may be used, but print quality will be reduced. The
stiffness is also important and must be balanced against thickness to
maintain print quality.
Media rolls to be loaded inside the printer should be wound with the
printable side facing outwards.
The media supply must not be exposed to dust, sand, grit, etc. Any hard
particles, however small, can damage the printhead.
0
Must not protrude outside the media.
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
213 mm (8.38 inches)
114.3 mm (4.50 inches)
25 mm (1.00 inches)
40 mm (1.57 inches)
