IP Routing Features
Overview of IP Routing
Parameter Description
ICMP Router An IP protocol that a router can use to advertise the IP addresses of its
Discovery router interfaces to directly attached hosts. You can enable or disable the
Protocol protocol at the Global CLI Config level.
(IRDP)
You also can enable or disable IRDP and configure the following protocol
parameters on an individual VLAN interface basis at the VLAN Interface
CLI Config level.
• Forwarding method (broadcast or multicast)
• Hold time
• Maximum advertisement interval
• Minimum advertisement interval
• Router preference level
Static route An IP route you place in the IP route table.
Default The router uses the default network route if the IP route table does not
network route contain a route to the destination. For the Series 5300XL Switches, enter
an explicit default route (0.0.0.0 0.0.0.0 or 0.0.0.0/0) as a static route in the
IP route table.
Parameter Description
IP address A Layer 3 network interface address; separate IP
addresses on individual VLAN interfaces.
ICMP Router Locally overrides the global IRDP settings. See table
Discovery 15-1 on page 15-5 for global IRDP information.
Protocol (IRDP)
IP helper address The IP address of a UDP application server (such as a
BootP or DHCP server) or a directed broadcast
address. IP helper addresses allow the routing switch
to forward requests for certain UDP applications from
a client on one sub-net to a server on another sub-net.
15-6

IP Interface Parameters for Routing Switches

Table 15-2 lists the interface-level IP parameters for routing switches.
Table 15-2. IP Interface Parameters – Routing Switches
Default
Disabled
No entries
None
configured
Default
None configured
Disabled
None configured
See page
15-17
15-18
15-13
15-15
See page
chapter 7
15-18
15-21
