HP Procurve 2650 Management And Configuration Manual page 338

802.1w Rapid Spanning Tree Protocol (RSTP) and 802.1d Spanning Tree Protocol (STP)
802.1p Spanning-Tree Protocol (STP)
Figure 13-14. The Default STP Screen With the Protocol Version Field Set to "RSTP"
13-32
To View and/or Configure Fast-Uplink STP. This procedure uses the
Spanning Tree Operation screen to enable STP and to set the Mode for fast-
uplink STP operation.
1. From the Main Menu select:
2. Switch Configuration . . .
4. Spanning Tree Operation
2. In the default STP configuration, RSTP is the selected protocol version.
If this is the case on your switch, you must change the Protocol Version
to STP in order to use Fast-Uplink STP:
• If the Protocol Version is set to RSTP (the default, as shown in this
example, go to step 3.
• If the Protocol Version is set to STP, the rest of the screen will appear
as shown in figure 13-16. In this case, go to step 4 on page 13-34.
