Replacing the AC Plug/Input Filter

To replace the AC plug and input filter assembly, you will need the following
parts and tools:
To replace the AC plug and input filter
1. Switch off the printer power and remove the power cord, the media cover,
2. Disconnect the three push-on connectors attached to the back of the AC
3. Remove the two screws securing the AC plug/input filter assembly to the
4. Install the new AC power plug and input filter assembly and secure it with
5. Reconnect the three push-on connectors removed in Step 2.
6. Install the electronics cover, the media cover, and the power cord, and
3600 line AC plug and filter assembly, Intermec Part No. 060246-001
ESD grounding strap
#1 and #2 Phillips screwdriver
Needlenose pliers
and the electronics cover.
plug/input filter assembly.
main deck plate and remove the assembly.
the two screws removed in Step 3.
check the printer for proper operation.
Remove and Replace Procedures
Push-on
connectors
AC power
O
plug & filter
(2 places)
3600M.062
