When Switch Acts As Server For Publickey Authentication - 3Com 4210G Series Configuration Manual

Figure 8-2 SSH client configuration interface
In the window shown in
enter the username and password. After entering the correct username (client001) and password
(aabbcc), you can enter the configuration interface.

When Switch Acts as Server for Publickey Authentication

Network requirements
As shown in
and the switch (the SSH server) for secure data exchange.
Publickey authentication is used, the algorithm is RSA.
Figure 8-3 Switch acts as server for publickey authentication
SSH client
192.168.1.56/24
Host
Configuration procedure
1) Configure the SSH server
# Generate RSA and DSA key pairs and enable SSH server.
<Switch> system-view
[Switch] public-key local create rsa
Figure 8-2, click Open. If the connection is normal, you will be prompted to
Figure 8-3, a local SSH connection is established between the host (the SSH client)
SSH server
Vlan-int1
192.168.1.40/24
Switch
8-14
