Application Environment of Static Routing

Before configuring a static route, you need to know the following concepts:
1) Destination address and mask
In the ip route-static command, an IPv4 address is in dotted decimal format and a mask can be either
in dotted decimal format or in the form of mask length (the digits of consecutive 1s in the mask).
2) Output interface and next hop address
While configuring a static route, you can specify either the output interface or the next hop address
depending on the specific occasion. For a NULL0 or loopback interface, if the output interface has
already been configured, there is no need to configure the next hop address
In fact, all the route entries must have a next hop address. When forwarding a packet, a router first
searches the routing table for the route to the destination address of the packet. The system can find
the corresponding link layer address and forward the packet only after the next hop address is
specified. The next hop address can not be a local interface IP address; otherwise, the route
configuration will not take effect.
3) Other attributes
You can configure different preferences for different static routes so that route management policies
can be applied more flexibly.

Configuring a Static Route

Configuration Prerequisites

Before configuring a static route, you need to finish the following tasks:
Configure the physical parameters for related interfaces
Configure the link-layer attributes for related interfaces
Configure the IP addresses for related interfaces

Configuration Procedure

Follow these steps to configure a static route:
To do...
Enter system view
Configure a static
route
Configure the default
preference for static
routes
Use the command...
system-view
ip route-static dest-address { mask | mask-length }
{ next-hop-address | interface-type interface-number
next-hop-address } [ preference preference-value ]
[ tag tag-value ] [ description description-text ]
ip route-static default-preference
default-preference-value
2-2
Remarks
—
Required
By default,
preference for
static routes is 60,
tag is 0, and no
description
information is
configured.
Optional
60 by default
