Quick Start Guide
1
Figure 1 - 6
Right View
1. Headphone-In Jack
2. Microphone-In Jack
3. Line-In Jack
4. S/PDIF-Out Jack
5. Cable (CATV)
*
Antenna Jack
6. Combined eSATA/
USB Port
7. USB 2.0 Port
8. Security Lock Slot
9. Power Button
*Enabled
with
Optional
Mini-PCI TV Tuner Only
See
Appendix A
for a more
detailed description of the
ports & jacks etc.
1 - 12 System Map: Right View
System Map: Right View
Note that the TV Tuner module options in Windows Vista is supported by the Windows
Media Center software which comes built-in to the Windows Vista Home Premium and
Ultimate Editions only.
If your purchase includes a TV Tuner option, and you are re-configuring your system for a
different system, you should install either Windows Home Premium or Ultimate Editions
only.
Note that the connections to the USB ports only fit one way, do not force them.
4
3
1 2
5
TV Tuner Module Support
USB Ports
6
9
7
8
