Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 5: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 9: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Page 10: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 11: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 12: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 15: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 16 Preface...
Page 17: Table Of Contents
Preface Contents Notice .................I Keyboard ..............1-10 FCC Statement .............II Function/Hot Key Indicators ........1-11 FCC RF Radiation Exposure Statement: ....III System Map: Front & Rear Views .......1-12 Instructions for Care and Operation ......V System Map: Left View ..........1-13 Power Safety .............VII System Map: Right &...
Page 18 Preface TouchPad and Buttons/Mouse ........2-10 Battery Life ..............3-12 Audio Features .............2-11 New Battery ..............3-12 Setup for Audio Recording ........2-12 Recharging the Battery with the AC/DC Adapter ..3-12 Setup for 5.1 Surround Sound ........2-13 Proper handling of the Battery Pack ......3-13 Adding a Printer ............2-15 Battery FAQ ..............3-14 USB Printer ...............2-15...
Page 19 Preface IEEE 1394 Filter ............4-6 Power On Boot Beep (Advanced Menu) .......5-8 GameKey Utility ............4-7 Battery Low Alarm Beep: (Advanced Menu) ....5-8 HotKey Utility ............4-7 Boot-time Diagnostic Screen: (Advanced Menu) ..5-8 Optional Drivers ............4-8 Security Menu ..............5-9 Wireless LAN .............4-8 Set Supervisor Password (Security Menu) ....5-9 PC Camera ..............4-8 Password on boot: (Security Menu) ......5-10...
Page 20 Preface 802.11b/g Driver Installation ........7-3 RAID Volume Data Verification and Repair ...7-44 Connecting to a Wireless Network ......7-4 Replacing and Reverting Recovery Intel® My WiFi Installation & Configuration ....7-7 and Master Volumes ..........7-44 Intel® Wi-Fi Link 5100/5300 Series Intel Turbo Memory Module ........7-46 My WiFi Driver Installation ........7-8 Intel Turbo Memory &...
Page 21 Preface e-SATA Port ..............A-2 Memory ................. C-2 HDMI-Out Port ............. A-3 Video Adapter ............... C-2 Headphone-Out Jack ............. A-3 BIOS ................C-2 Line-In Jack ..............A-3 Storage ................C-2 Microphone-In Jack ............A-4 Pointing Device ............. C-2 Mini-IEEE 1394 Port ............ A-4 Keyboard ...............
Page 22 Preface...
Page 23: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 24: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 25: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows Vista etc.) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 26: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, TV Tuner Module you will find the Windows Vista (with Service Pack 2) operating system is support- Support Note that the TV Tuner module (factory) option...
Page 27: System Startup
Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. 3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 28: Closing The Lid/Lcd Panel
Quick Start Guide Closing the Lid/LCD Panel Make sure you close the lid/LCD by placing your hand in the middle of the panel, and carefully press down until the LCD latches click into place (do not exert pressure from the sides of the lid/LCD as this can cause dam- age to the latches, case or lid/LCD).
Page 29: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 3 LCD Panel Open Optional Built-In Wireless Device Operation PC Camera Aboard Aircraft LED Power & The use of any portable electronic Communication transmission devices (e.g. WLAN or Indicators Bluetooth) aboard aircraft is usually Built-In prohibited.
Page 30: Led Indicators
Quick Start Guide LED Indicators Icon Color Description The two sets of LED indicators (LED Status Indica- Orange DC Power is Plugged In tors and LED Power & Communication Indicators) on the computer display helpful information about the Green The Computer is On current status of the computer.
Page 31: Hot Key Buttons & Game Keys
Quick Start Guide Hot Key Buttons & Game Keys The two Game Keys on the left of the computer allow macros to be configured for common keystrokes used These buttons give instant access to the default Inter- in applications, as long as the driver is installed (see net browser and e-mail program, and to a user-defined “Game Keys”...
Page 32: Keyboard
Quick Start Guide Keyboard The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 11 for full function key combination details.
Page 33: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “HotKey Utility”...
Page 34: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 6 Front & Rear Views LCD Latches Consumer Infrared Transceiver Line-In Jack S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Speakers Vent/Fan Intake DC-In Jack 10. DVI-Out Port Overheating *Enabled with Optional To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in- TV Tuner Only take(s) while the computer is in use.
Page 35: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 7 Left View HDMI-Out Port e-SATA Port Cable (CATV) Antenna Jack 4. RJ-11 Phone Jack 5. RJ-45 LAN Jack Mini-IEEE 1394 Port 6. Mini-IEEE 1394 Port The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Make sure 7.
Page 36 Quick Start Guide Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 37: System Map: Right & Bottom Views
Quick Start Guide System Map: Right & Bottom Views Figure 1 - 8 Right & Bottom Views USB Ports Security Lock Slot Fan Outlet/Intake Battery (Secondary HDD Bay - HDD3) Battery Information Primary HDD Always completely dis- Bay (HDD1 & 2) charge, then fully charge, a Component Bay new battery before using it.
Page 38: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 39: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - 1.
Page 40: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV (connected to the DVI-Out port/HDMI-Out port) as your display device. Figure 1 - 10 - Display Settings & NVIDIA Control Panel NVIDIA Display Mode Description Single...
Page 41: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 16) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 42 Quick Start Guide 1 - 20...
Page 43: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...
Page 44: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive(s) is(are) used to store your data in the computer. The hard Power Safety disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 45: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page C - 2). The Adjustment optical device is usually labeled “Drive D:”...
Page 46: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 47: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 48: 7-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 49: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 50: Application Hot Key
Storage Devices, Mouse, Audio & Printer Application Hot Key To configure a program to open when the application hot key button is pressed Hot Key Driver (Windows Media Player is the default program), follow the instructions below. Double-click the icon bring up the configuration Double-click the Hot Key driver icon in the taskbar.
Page 51: Game Keys
Storage Devices, Mouse, Audio & Printer Game Keys The two game hot keys on the left of the computer allow macros to be configured for common keystrokes used in applications (the keys can assigned macros for any program, not only games). To configure the keys follow the instructions below (make sure you have installed the GameKey Utility driver - see “GameKey Utility”...
Page 52: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 53: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 54: Setup For Audio Recording
Storage Devices, Mouse, Audio & Printer Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the taskbar icon and select Sound Manager).
Page 55: Setup For 5.1 Surround Sound
Storage Devices, Mouse, Audio & Printer Setup for 5.1 Surround Sound To setup your system for 5.1 surround sound you will need to connect the audio ca- bles to the Line-In and Microphone-In jacks. Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View.
Page 56 Storage Devices, Mouse, Audio & Printer Plug the front speaker cables into the Headphone-Out Jack. Plug in the other cables (you may require an adapter to connect each cable to the appropriate jack e.g a stereo mini to dual RCA adapter) from your speakers as follows: •...
Page 57: Adding A Printer
Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.
Page 58 Storage Devices, Mouse, Audio & Printer 2 - 16...
Page 59: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 60: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 61: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate/Shut ways shut your comput- er down by choosing the Down hot key button when it is pressed for less than 4 seconds (pressing and holding...
Page 62: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 63 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 64: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 65: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 66: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 67: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status Icon Color To Resume send the computer to...
Page 68: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 69: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 70: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 71: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 72: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 73 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 74 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 75: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
Page 76: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or click Op- Drivers Installer menu below.
Page 77: Manual Driver Installation
Drivers & Utilities Manual Driver Installation Driver for Windows Vista SP2 Page To install the drivers manually click the Browse CD/ DVD button in the Drivers Installer application and Chipset Page 4 - 5 browse to the executable file in the appropriate driver Page 4 - 5 Video folder.
Page 78: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 79: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Chipset Insert the Device Drivers & Utilities + User’s Manual 1. Click 1.Install Chipset Driver > Yes. disc and click Install Drivers (button). 2. Click Next > Yes > Next > Next. 3. Click Finish to restart the computer. Video Driver Installation General Guidelines 1.
Page 80: Modem
Drivers & Utilities Modem TouchPad 1. Click 5.Install Modem Driver > Yes. 1. Click 7.Install Touchpad Driver > Yes. 2. Click Next > Finish. 2. Click OK. 3. Click Restart Now to restart the computer. 3. The modem is now ready for configuration. 4.
Page 81: Gamekey Utility
Drivers & Utilities GameKey Utility 1. Click 10.Install GameKey Utility > Yes. 2. Click Next. Windows Update 3. Click Finish to restart the computer. After installing all the drivers make sure you enable Win- 4. See “Game Keys” on page 2 - 9 for configura- dows Update in order to get all the latest security up- tion instructions.
Page 82: Optional Drivers
Drivers & Utilities Optional Drivers Wireless LAN See the pages indicated for the driver installation pro- See the appropriate install procedure for your WLAN cedures for any modules included in your purchase op- module in “Wireless LAN Module” on page 7 - tion.
Page 83: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 84: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 85: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 86: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds...
Page 87: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 88: Main Menu
BIOS Utilities Main Menu Figure 5 - 1 Phoenix SecureCore(tm) Setup Utility Main M ai n Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [03/04/2009] <Tab>, <Shift Tab>, or System Memory: 633 KB <Enter> selects field. Extended Memory: 2045 MB BIOS Revision:...
Page 89: Advanced Menu
BIOS Utilities Advanced Menu Phoenix SecureCore(tm) Setup Utility Main A A dvanced Security Boot Exit RAID/AHCI Advanced Enable/Disable Item Specific Help Setup Warning Warning Setting items on this menu to incorrect values may cause your system to malfunction. DO NOT Enable/Dis- RAID/AHCI Mode.
Page 90: Legacy Usb Support: (Advanced Menu)
BIOS Utilities Legacy USB Support: (Advanced Menu) Choose “Enabled” if you intend to use USB devices in systems which do not nor- mally support USB functionality (e.g. DOS). The default setting is “Enabled” and does not need to be changed if you intend to use your USB devices in Windows. Reset Configuration Data: (Advanced Menu) This item is set to No as default.
Page 91: Security Menu
BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Security Menu Security Main Advanced S S e e c c u u r r i i t t y y Boot Exit changes Item Specific Help Supervisor Password Is: Clear make here affect the Set Supervisor Password [Enter] access to the Setup...
Page 92: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system (see Password Warning the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password, then...
Page 93: Boot Menu
BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 4 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: USB KEY: Keys used to view or USB HDD: configure devices: PCI SCSI: P0-FUJITSU MHY2120BH Up and Down arrows PCI BEV: P4-HL-DT-ST DVDRAM GSA-T50 PCI BEV: Realtek Boot Agent...
Page 94: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 5 Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to Discard Changes CMOS.
Page 95: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 96: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 97: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Loosen screws before undertaking any...
Page 98: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) RAID Hard Disks hard disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2).
Page 99 Upgrading The Computer Remove screws and pull the tab to release the cable from the connector Lift the hard disk assembly out of the computer. HDD System Warning Remove screws (if two hard disks are installed). Separate the hard disk(s) from the bracket and connector cable New HDD’s are blank.
Page 100 Upgrading The Computer Removing the Hard Disk(s) in the Secondary HDD Bay Turn off the computer, and turn it over and remove the battery. The secondary hard disk bay is located under the battery compartment. RAID Hard Disks Remove screw All hard disks in a RAID Slide the hard disk assembly in the direction of the arrow should be identical (the...
Page 101: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has three memory sockets for 204 pin Small Outline Dual In-line Contact Warning (SO-DIMM) DDR III (DDR3) type memory modules (see “Memory” on page C - 2). The total memory size is automatically detected by the POST routine once you Be careful not to touch turn on your computer.
Page 102 Upgrading The Computer Remove screws from the RAM fan, and disconnect cable Remove the RAM fan unit Figure 6 - 6 Fan, Heat Sink Unit Screws & Cable Connectors Caution The heat sink, and CPU area in general, contains parts which are subject to high temperatures.
Page 103 Upgrading The Computer Fully loosen screws in the order indicated here (and on the label). Disconnect cable Carefully (make sure all the screws are sufficiently loosened and cables disconnected) remove the heat sink and fan unit Figure 6 - 7 Heat Sink Removal Caution...
Page 104 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the arrows in Figure 6 - 8 10. The RAM module will pop-up, and you can remove it. Single Memory Module Installation If your computer has a sin-...
Page 105: Upgrading A Third System Memory (Ram) Module
Upgrading The Computer Upgrading a Third System Memory (RAM) Module If you wish to add a third memory module follow the procedure below (note the side- bar warning on RAM speeds). RAM Module Speeds Turn off the computer, and turn it over and remove the battery. Use either 1066MHz OR Turn the computer back over to access the keyboard.
Page 106 Upgrading The Computer Lift the keyboard up, but be careful not to twist the keyboard ribbon cable Remove screws and remove the keyboard plate Figure 6 - 10 Keyboard Plate Screws Figure 6 - 11 Keyboard Plate Removal 6 - 12 Upgrading the System Memory (RAM)
Page 107 Upgrading The Computer Gently pull the two release latches ( ) on the sides of the memory socket in the direction indicated by the arrows in Figure 6 - 12 The RAM module will pop-up, and you can remove it. Figure 6 - 12 Third RAM Module Removal...
Page 108: Upgrading The Optical (Cd/Dvd) Device(S)
Upgrading The Computer Upgrading the Optical (CD/DVD) Device(s) Turn the computer off, turn it over and remove the battery. Locate the hard disk bay cover and remove screws Remove the bay cover Remove screw and use the screwdriver to push the optical device(s) out of the computer at point Figure 6 - 13 Removing the CD/...
Page 109: Upgrading The Video Card
Upgrading The Computer Upgrading the Video Card If you intend to upgrade or add another VGA card follow the procedures outlined Warranty Warning here. However please check with your service representative first to make sure your computer can support more than one video card, and that you are not going to void Please check with your your warranty.
Page 110 Upgrading The Computer Remove screws from the video card fan and disconnect the fan cable Figure 6 - 15 Video Card Fan Screws Remove screws from the heatsink in the order indicated on the label. Figure 6 - 16 Heat Sink Screws 6 - 16 Upgrading the Video Card...
Page 111 Upgrading The Computer Grip the handle and carefully remove the heatsink Remove screws & from the video card. Carefully remove the video card Caution The heat sink, and video card area in general, contains parts which are subject to high tempera- tures.
Page 112 Upgrading The Computer Installing a New Video Card Prepare to fit the video card into the slot by holding it at about a 30° angle. Contact Warning Be careful not to touch the metal pins on the VGA card’s connecting edge.
Page 113 Upgrading The Computer Fit the connectors firmly into the socket, straight and evenly. DO NOT attempt to push one end of the card in ahead of the other. Figure 6 - 19 Video Card Insertion Procedure The card’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the socket as it will go (none of the gold colored contact should be showing).
Page 114 Upgrading The Computer Secure the card with screws & (Figure 6 - 17 on page 6 - 17). Place the heatsink back on the card, and secure the screws in the order indicated Figure 6 - 16 on page 6 - Attach the video card fan and secure with the screws as indicated in Figure 6 - 15 on page 6 -...
Page 115: Modules
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 116: Wireless Lan Module
Modules Wireless LAN Module If you have included an Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) or Wireless Device 802.11b/g WLAN module in your purchase option, make sure that the Wireless LAN Operation Aboard module is on before installing the driver. Aircraft Use the Fn + F11 key combination (see Table 1 - 4, on page 1 -...
Page 117: Intel® Wi-Fi Link 5100/5300 Series (802.11 A/G/N) Driver Installation
Modules Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.
Page 118: Connecting To A Wireless Network
Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Click icon...
Page 119 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 3 Connecting Move the cursor over the taskbar icon...
Page 120 Modules To disconnect from the wireless network you can click the taskbar wireless icon and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network...
Page 121: Intel My Wifi Installation & Configuration
Modules Intel My WiFi Installation & Configuration ® Intel® My WiFi Technology uses your WLAN module to allow you to connect up to eight other WiFi enabled devices (e.g. digital cameras, other computers, cell Intel® My WiFi Help phones, handheld devices etc.) to your computer (similar to Bluetooth), while still To get help on Intel®...
Page 122: Intel® Wi-Fi Link 5100/5300 Series My Wifi Driver Installation
Modules Intel® Wi-Fi Link 5100/5300 Series My WiFi Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.
Page 123 Modules Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon Click Enable (on the first run of the program there will be no connected...
Page 124 Modules Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Network and Sharing Center (Network and Internet). Click Manage Network Connections. Click Manage Network Connections Figure 7 - 8 Network and Sharing Center Right-click Intel My WiFi STA (Station) in Network Connections and select Properties.
Page 125 Modules Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Intel My WiFi PAN under Home Networking Connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”. Select Intel My WiFi PAN.
Page 126 Modules 10. A message will appear to inform you that the LAN adapter will be set to use the IP address 192.168.0.1. Figure 7 - 11 11. Click Yes to enable Internet Connection Sharing. IP Address Warning IP Addresses The Intel® My WiFi de- fault gateway IP ad- dress is 192.168.0.1.
Page 127 Modules 14. Click Profiles, click Intel Wireless PAN and click Edit. Figure 7 - 13 IP Address Warning 15. You can change the Profile Name and Network Name to your personal preferences in General (tab). Profile and Network Names The Profile Name is the name as Figure 7 - 14 displayed on your computer in the Intel®...
Page 128 Modules 16. Click Security (tab). 17. Change the Security Type to WEP and the Encryption Type to 64bit. 18. Enter a password (5 characters long) in the Passphrase box. 19. Click OK. Figure 7 - 15 Intel® My WiFi Profile Settings - Security 7 - 14 Wireless LAN Module...
Page 129 Modules 20. Click Sharing (tab). 21. Make sure Filter Network Traffic and DHCP and DNS Server are Disabled. 22. Click OK. Set Filter Network Traffic & DHCP and DNS Servers Figure 7 - 16 to Disabled. Intel® My WiFi Profile Settings - Sharing Wireless LAN Module 7 - 15...
Page 130 Modules 23. Click Advanced (tab). 24. Make sure the Default Channel is set to Channel 1, 6 or 11. 25. Click OK. Figure 7 - 17 Intel® My WiFi Profile Settings - Advanced 7 - 16 Wireless LAN Module...
Page 131 Modules 26. Double-click Intel My WiFi PAN (Personal Area Network) in Network Connections. 27. Click Details to display the Network Connection Details. Figure 7 - 18 Intel My WiFi PAN Network Connection Details (Network Connections) Wireless LAN Module 7 - 17...
Page 132 Modules 28. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon 29. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Page 133: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 134: Pc Camera Module
Modules PC Camera Module The PC Camera module uses the BisonCap application to capture video files. Be- Latest PC Camera fore installing the PC Camera driver, make sure that the optional PC Camera is on. Driver Information Use the Fn + F10 key combination (see Table 1 - 4, on page 1 - 11) to toggle pow- Check the disc, and any ac-...
Page 135: Pc Camera Driver Installation
Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3. Click 2.Install WebCam Driver > Yes. The PC Camera module 4.
Page 136 Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 137 Modules Figure 7 - 21 Audio Setup for PC Camera Right-click PC Camera Module 7 - 23...
Page 138 Modules BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate process - see Set Capture File below).
Page 139 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 140 Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 141 Modules Zoom The BisonCap program allows you to zoom the camera in and out. Run the BisonCap program. Go to Zoom and select Zoom Out/Zoom In. Bison Cap Figure 7 - 23 Zoom/Setting Snapshot Folder Taking Still Pictures The Snapshot folder’s The BisonCap program allows you to take still pictures.
Page 142: Bluetooth Module
Modules Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows Vista, and therefore does not require a driver. Use Operation Aboard the Fn + F12 key combination (see Table 1 - 4, on page 1 - 11) to toggle power to Aircraft the Bluetooth module (when the Bluetooth module is on, the...
Page 143: Bluetooth Configuration In Windows Vista
Modules Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On Bluetooth icon in the...
Page 144 Modules To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear.
Page 145 Modules To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...
Page 146: Tv Tuner Module
Modules TV Tuner Module If your purchase configuration includes the optional Hybrid (Analog & Digital) TV Antenna USB Mini-Card TV Tuner module, you will be supplied with a remote control unit The TV antenna sup- and appropriate antenna and fittings for the module. Software support for the TV plied with any TV Tuner Tuner module is provided by Windows Media Center in Windows Vista (Home module is intended for...
Page 147: Consumer Infrared Driver
Modules Consumer Infrared Driver 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. TV Tuner Module 2. Click Option Drivers (button). Support 3. Click 3.Install CIR Driver > Yes. Note that the TV Tuner 4.
Page 148: Digital Tv Broadcast Signal
Modules Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear digital terrestrial TV broadcast signal. The passive antenna provided should provide a clear signal when CATV Cable Safety placed beside a window. If the signal is not clear then you can purchase an active Make sure that your antenna (it should also be placed beside a window) to improve the signal.
Page 149: Setting Up Sata Raid Or Ahci Modes
Modules Setting Up SATA RAID or AHCI Modes AHCI Mode RAID Hard Disks Advanced Host Controller Interface (AHCI) is an interface specification that allows All hard disks in a RAID the storage driver to enable advanced serial ATA features such as Native Command should be identical (the Queuing (for maximum hard disk efficiency and performance).
Page 150 Modules RAID Level Description Table 7 - 1 RAID Levels Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive.
Page 151: Sata Raid Or Ahci Setup Procedure (Bios)
Modules SATA RAID or AHCI Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode Selection" and press Enter (see RAID and Ready- page Drive Compatibility • Select either “RAID” or “AHCI”. On a system configured in RAID mode, a condi- Press Esc and go to the Boot menu.
Page 152: Raid Setup (Intel Matrix)
Modules RAID Setup (Intel Matrix) Press Ctrl + i to enter RAID configuration menu. Figure 7 - 29 Intel(R) Matrix Storage Manager option ROM v8.5.0.1030 ICH10R wRAID5 Copyright (C) 2003-08 Intel Corporation. All Rights Reserved. Intel(R) Matrix [ MAIN MENU Create RAID Volume Reset Disks to Non-RAID Storage Manager...
Page 153: Intel® Matrix Driver Installation
Modules 10. This will now return to the main menu. Intel(R) Matrix Storage Manager option ROM v8.5.0.1030 ICH10R wRAID5 Copyright (C) 2003-08 Intel Corporation. All Rights Reserved. [ MAIN MENU Create RAID Volume Reset Disks to Non-RAID Figure 7 - 30 Delete RAID Volume Recovery Volume Options 5.Exit...
Page 154: Windows Installation For Recovery Level Raid Systems
Modules Windows Installation for Recovery Level RAID Systems When you install Windows Vista for Recovery level RAID systems you will need to provide the driver for the RAID system as per the instructions below. Firstly you will need to go to an operable computer and copy the driver from the Device Drivers & Utilities + User’s Manual disc to a USB Flash drive, external USB hard disk or ex- ternal floppy disk drive and floppy diskette.
Page 155 Modules Select your Windows version (e.g. Windows Vista Ultimate) and click the “I have selected the edition of Windows that I purchased” tickbox and then click Next. 10. Click “I accept the license terms” tickbox and click Next. 11. Click to Custom (advanced). 12.
Page 156: Intel® Matrix Driver Installation
Modules Intel Matrix Driver Installation ® 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. e-SATA Port 2. Click Option Drivers (button). Install the Intel Matrix 3. Click 4.Install TM&iMSM Driver > Yes. Storage driver to dis- 4.
Page 157: Intel® Matrix Storage Manager
Modules Intel® Matrix Storage Manager If a hard drive member of a RAID volume is reported as “Degraded” or “Failed” it may be possible to recover the volume. If the volume cannot be restored then you will need to recreate the RAID volume and restore the data from a back up. The Help menu (press F1 or select Contents and Index from the Help menu) provides in- structions on how to recover or recreate RAID Volumes.
Page 158: Raid Volume Data Verification And Repair
Modules RAID Volume Data Verification and Repair The RAID volume data verification process identifies any inconsistencies or bad data on a RAID 0, RAID 1 or Recovery volume. The table outlines what occurs for each RAID level: RAID Verify Verify & Repair Level RAID 0 Bad blocks are identified.
Page 159 Modules Verifying and Repairing RAID Volume Data Run the Intel® Matrix Storage Console from the Intel® Matrix Storage Man- ager in the Programs/All Programs menu. Click View > Advanced Mode. Right-click on the RAID volume and select either Verify Volume Data or Verify and Repair Volume Data.
Page 160: Intel Turbo Memory Module
Modules Intel Turbo Memory Module If you have included an Intel Turbo Memory (Robson) NAND flash memory card e-SATA Port module in your purchase option, then you will need to enable AHCI or RAID mode Support in the BIOS (see “Advanced Menu”...
Page 161: Intel Turbo Memory & Matrix Storage Setup And Driver Installation
Modules Intel Turbo Memory & Matrix Storage Setup and Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. ReadyBoost Issue 2. Click Option Drivers (button). When the Intel® Turbo 3. Click 4.Install TM&iMSM Driver > Yes. Memory Console 4.
Page 162 Modules Intel Turbo Memory Dashboard (User Pinning Supported Only) The Intel Turbo Memory Dashboard allows you to pin an application or file to load into the Intel Turbo Memory NAND cache for performance acceleration. Help ® Run the Intel Turbo Memory Dashboard from the Programs/All Programs Click the Help icon ®...
Page 163 Modules Pinning an Application (User Pinning Supported Only) 1. The Intel ® Turbo Memory Dashboard allows you to select files and applications to accelerate and therefore open faster and display quicker. Unpinning an 2. Applications will be listed in the Applications Window on the right. Application 3.
Page 164 Modules Custom File Sets (User Pinning Supported Only) A Custom File Set allows you to group applications and files to accelerate. These sets can be moved easily in and out of the Accelerated Window which is of benefit when space is limited. You need to create the custom file set before dragging the set to the accelerated window.
Page 165 Modules Intel Turbo Memory Console (All Modules) 1. Run the Intel ® Turbo Memory Console from the Programs/All Pro- grams menu (Intel ® Turbo Memory). Windows 2. You can enable/disable Windows ReadyBoost and Windows ReadyDrive ReadyBoost from the Intel ® Turbo Memory Console. If your module supports User Pinning (i.e.
Page 166 Modules 7 - 52...
Page 167: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 168: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 169: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a DVD wallet.
Page 170: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 171: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 172 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 173: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present but it doesn’t work. and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 174 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 175 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 176 Troubleshooting Problem Possible Cause - Solution The TouchPad doesn’t The Touchpad has been disabled. Press the Touchpad toggle (Fn + F1) key combination (make work. sure you have installed the Touchpad driver. The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark.
Page 177 Troubleshooting Problem Possible Cause - Solution Nothing appears on the You have selected an external display as the default display device. The PC Camera application screen when the PC software needs to be run while the default notebook LCD is the selected display device. Camera software is run.
Page 178 Troubleshooting Problem Possible Cause - Solution When a DVD is played in This is an issue with Windows Media Player/Media Center and audio output through the S/PDIF- Windows Media Player/ Out Jack. We recommend that you use the Power DVD application to play DVDs. Media Center, the audio track in other languages (commentaries etc.) is...
Page 179 Troubleshooting Problem Possible Cause - Solution The on screen volume When adjusting the volume for an HDMI connected display device the on screen volume indicator indicator will not display the volume level as it is being adjusted. If you do need to see the does display volume level as it is being adjusted you can display the Windows volume level indicator or the...
Page 180: Screen Resolution Error
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
Page 181 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. Screen Resolution Error 8 - 15...
Page 182 Troubleshooting 8 - 16...
Page 183: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 184: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) Cable (CATV)
Page 185: Hdmi-Out Port
Interface (Ports & Jacks) Item Description HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external monitor, TV or HDMI Flat Panel Display etc. as a display device (see “”...
Page 186: Microphone-In Jack
Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. Mini-IEEE 1394 Port This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.
Page 187: Security Lock Slot
Interface (Ports & Jacks) Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
Page 188 Interface (Ports & Jacks) A - 6...
Page 189: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Driver Versions NVIDIA Video Driver Installation Note that there are two driv- er versions supplied with Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - this video card.
Page 190: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 18) control panel. To access the Ge- Click Advanced Settings (button). Force..
Page 191 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 192 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 193: Display Devices
NVIDIA Video Driver Controls Display Devices Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI Display Devices (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use a Besides built-in converter to convert the signal from DVI to VGA).
Page 194: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same content. Dualview Mode/Extended Mode Dualview/Extended Mode treats both connected displays as separate devices, and they act as a virtual desktop resulting in a large workspace.
Page 195: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 196 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel (Ver 1) Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel”...
Page 197 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel (Ver 2) Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel”...
Page 198 NVIDIA Video Driver Controls Click the tickbox alongside any display you wish to use. Click Apply > Yes to save the changes. The default display mode will be in Extended mode (i.e the desktop will be Display Not Shown extended on to the external display - see “Display Devices”...
Page 199 NVIDIA Video Driver Controls Enabling Clone Mode (Ver 2) Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel” on page B - Double-click Display (if the sub-menus are not visible), and then click Set up multiple displays.
Page 200 NVIDIA Video Driver Controls To switch back to Extended Mode right-click one of the display icons and click “Clone Laptop Display and..” (to remove the tick) option from the pop-up menu and click Apply. Figure B - 9 Switch to Extended Mode B - 12 Attaching Other Displays...
Page 201 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 202 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel).
Page 203: Hdmi Audio Configuration
NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. Windows Audio Setup for HDMI Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 204 NVIDIA Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • If you disconnect the HDMI cable the default audio playback device will not If you are using a third revert to speakers until the computer is restarted (if you do not wish to restart the party application to play...
Page 205: Enabling Tv Display (Ver 1
NVIDIA Video Driver Controls Enabling TV Display (Ver 1) To display desktop images on a TV, connect the TV to your computer by using an Detect Displays HDMI cable/DVI cable from the TV to the HDMI-Out port/DVI-Out port (if sup- ported by your TV).
Page 206 NVIDIA Video Driver Controls Changing the TV Signal Format (Dualview Mode Only) When the TV is enabled as a display device, and Dualview is the selected display mode, click the sub-menus under Video & Television. Click “Change the signal or HD format” Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
Page 207: Enabling Tv Display (Ver 2
NVIDIA Video Driver Controls Enabling TV Display (Ver 2) To display desktop images on a TV, connect the TV to your computer by using an Detect Displays HDMI cable/DVI cable from the TV to the HDMI-Out port/DVI-Out port (if sup- ported by your TV).
Page 208: Changing The Tv Signal Or Hd Format
NVIDIA Video Driver Controls Changing the TV Signal or HD Format When the TV is enabled as a display device click the sub-menus under Video & Television. Click “Select the format you would like to use.”. Select the TV signal format you would like to use. Apply the settings, and then click Yes to save the changes.
Page 209: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 210: Processor
Specifications Processor Video Adapter Keyboard Intel® Core® i7 Processor nVIDIA® GeForce GTX 280M PCIe *16 “WinKey” keyboard (with embedded Video Card numeric keypad) i7-965 (3.20 GHz, 6.4 GT/s, 8M L3 Three Instant Keys (WWW, e-mail, 1GB GDDR3 Video RAM on board Cache, 45nm, LGA1366 Package) Application) ®...
Page 211: Card Reader
Specifications Card Reader Interface Operating System Embedded 7-in-1 Card Reader (MS/ MS Four USB 2.0 Ports Windows Vista Home Premium/ Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Business/ Enterprise/ Ultimate One HDMI (High-Definition Multimedia Duo) Note: MS Duo/ Mini SD/ RS MMC Interface) Port with Audio Output (with Cards require a PC adapter HDCP Support)
Page 212: Environmental Spec
Specifications Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Dimensions & Weight 397mm (w) * 298mm (d) * 51 - 60mm (h) 5.4 kg Optional One 12.7 mm Super Multi/Blu-Ray SATA Optical Device Drive PCIe or USB Mini-Card Wireless LAN...

EUROCOM Notebook V09.2.00 User Manual

Quick Start Guide

Storage Devices, Mouse, Audio & Printer

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules

Troubleshooting

Interface (Ports & Jacks)

NVIDIA Video Driver Controls

Specifications

Quick Links

Need help?

Questions and answers

Related Manuals for EUROCOM Notebook V09.2.00

Summary of Contents for EUROCOM Notebook V09.2.00

Table of Contents
