Quick Start Guide
1

System Map: Right View

Figure 1 - 7
Right View
1. Optical Device
Drive Bay (for CD/
DVD Device - see
page 2 - 3)
2. 1 * USB 2.0 Port
3. GPS Antenna
Socket (for optional
GPS Module)
4. Serial (COM1) Port
5. Security Lock Slot
1 - 14 System Map: Right View
Changing DVD Regional Codes
Go to the Control Panel and double-click De-
vice Manager (Hardware and Sound), then
click the + next to DVD/CD-ROM drives.
Double-click on the DVD-ROM device to
bring up the Properties dialog box, and se-
lect the DVD Region (tab) to bring up the
control panel to allow you to adjust the region-
al code (see "DVD Regional Codes" on
page 2 - 5).
DVD region detection is device dependent,
not OS-dependent. You can select your mod-
ule's region code 5 times. The fifth selection
is permanent. This cannot be altered even if
you change your operating system or you use
the module in another computer.
1
Disk Eject Warning
Don't try to eject a CD/DVD while the system is
accessing it. This may cause the system to
"crash". Stop the disk first then eject it, or press
the stop button twice.
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g.
due to an unexpected power interruption) you
may push the end of a straightened paper clip
into the emergency eject hole. Do not use a
sharpened pencil or any object that may break
and become lodged in the hole. Don't try to re-
move a floppy disk/CD/DVD while the system is
accessing it. This may cause the system to
"crash".
3
2 3 4
