Quick Start Guide
1
Figure 1 - 2
LCD Panel Open & Top
View
1. Optional Built-In PC
Camera
2. LCD
3. LED Status Indicators
4. Touch Sensor
Instant Keys
5. 8 * Gaming Keys
6. Keyboard
7. TouchPad and
Buttons
8. Fingerprint Reader
Module (optional)
9. LED Power Indicators
10. LCD Panel Color
LED
See
Appendix A
for a more
detailed description of the
ports & jacks etc.
1 - 6 System Map: LCD Panel Open & Top View
System Map: LCD Panel Open & Top View
3
5
8
1
2
4
6
7
9
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic
transmission devices (e.g. WLAN
or Bluetooth) aboard aircraft is usu-
ally prohibited. Make sure any wire-
less modules are OFF if you are
using the computer aboard aircraft.
Use the appropriate function key
combination/Touch Sensor Key to
toggle power to any wireless mod-
ules, and check the indicators to
see if any modules are powered on
or not (see
Table 1 - 2, on page 1
-
8).
