System Map: Right View

1
Changing DVD Regional Codes
Go to the Control Panel and double-click System >
Hardware (tab), click Device Manager, then click the
+ next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties box,
and select the DVD Region (tab) to bring up the con-
trol panel to allow you to adjust the regional code (see
"DVD Regional Codes" on page 2 -
DVD region detection is device dependent, not OS-
dependent. You can select your module's region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
6 7 8
2 3 4 5
5).
1.
10
9 8
2.
3.
11
4.
5.
6.
7.
8.
9.
10. DC-In Jack
11. CATV Jack (Enabled with
CD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unex-
pected power interruption) you may push the end of a straight-
ened paper clip into the emergency eject hole. Do not use a
sharpened pencil or similar object that may break and become
lodged in the hole.
System Map: Right View 1 - 13
Quick Start Guide
Figure 1 - 8 - Right View
Primary Optical Device Bay (for
CD/DVD Type Device)
Headphone-Out Jack
Microphone-In Jack
S/PDIF-Out Jack
Line-In Jack
Mini-IEEE 1394a Port
RJ-11 Phone Jack
2 * USB 2.0 Ports
Speaker
Optional Mini-PCI TV Tuner
Only)
