System Map: Right View

1 2 3
Both Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices.
The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats.
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
4
5 6
Mini-IEEE 1394 Port
ExpressCard Slot
7-in-1 Card Reader
Quick Start Guide
Figure 1 - 6 - Right View
1. Headphone-Out Jack
2. Microphone-In Jack
7
3. 7-in-1 Card Reader
4. Express Card Slot
5. Mini-IEEE 1394 Port
6. 2 * USB 2.0 Ports
7. Speaker
USB Ports
Note that the connections to
the USB ports only fit one
way, do not force them.
System Map: Right View 1 - 13
