System Map: Right View - EUROCOM Notebook User Manual

Quick Start Guide
1
Figure 1 - 6
Right View
1. Headphone-In Jack
2. Microphone-In Jack
3. Line-In Jack
4. S/PDIF-Out Jack
5. Cable (CATV)
*
Antenna Jack
6. Combined eSATA/
USB Port
7. USB 2.0 Port
8. Security Lock Slot
9. Power Button
*Enabled with Optional
Mini-PCI TV Tuner Only
See Appendix A for a more
detailed description of the
ports & jacks etc.

1 - 12 System Map: Right View

System Map: Right View
Note that the TV Tuner module (factory) option is supported by the Windows Media Cen-
ter software. Windows Media Center is not included in Starter or Home Basic versions
of Windows 7.
Note that the connections to the USB ports only fit one way, do not force them.
4
3
1 2
5
TV Tuner Module Support
USB Ports
6
9
7
8
