Modules
Figure 7 - 8
MediaShield BIOS
Array Detail
7
7 - 10 RAID Setup
16. Press Enter to access the Array Detail window which displays information on the
selected Array.
RAID Mode :
Stripe Width :
17. If you want to mark a disk as empty and wipe out all the contents (note that when
you clear the MBR all data will be destroyed), then press C.
18. Press Y to wipe out all the data, otherwise press N.
19. Press Enter to return to the Array List window, and then press Ctrl + X to exit.
20. You will now need to install the Windows OS.
21. Insert the Microsoft Windows Vista OS CD into the CD/DVD drive, and connect
an external USB flash drive to the notebook computer (make sure that the CD/
DVD drive is set as the first device in the "Boot priority order") with.
22. Press a key when you see the message "Press any key to start up from the CD/
Press any key to boot from CD".
23. Windows Vista will prompt you with a Load Driver warning.
24. Click Browse and navigate to the RAID driver location folder on the USB flash
drive and click OK.
Array 2 : NVIDIA STRIPE 223.58G
- Array Detail -
Striped
2 Stripe Block: 64K
Port Index Disk Model
0.0 0 FUJITSU MHY2120BH
0.2 1 FUJITSU MHZ2250BH G2
[R] Rebuild [D] Delete [C] Clear MBR
Capacity
111.79GB
232.88GB
[ENTER] Return
