Communication; Operating System; Power Management; Physical Dimensions & Weight - EUROCOM Notebook V09.1.00 User Manual

Specifications

Communication

Built-In Giga Base-TX Ethernet LAN
Bluetooth 2.1 + EDR (Enhanced Data
Rate) Module (Factory Option)
Intel® WiFi Link 5300 Series (3*3 -
802.11a/g/n) Wireless LAN PCIe
interface Mini-Card Module (Option)
Intel® WiFi Link 5100 Series (1*2 -
802.11a/g/n) Wireless LAN PCIe
interface Mini-Card Module (Option)
3rd Party 802.11b/g Wireless LAN PCIe
interface Mini-Card Module (Option)
2.0M or 3.0M Pixel PC Camera Module
with USB interface (Factory Option)

Operating System

Windows Vista Home Premium/
Business/ Enterprise/ Ultimate
Note that the TV Tuner module (factory)
option in Windows Vista is supported by
the Windows Media Center software
which comes built-in to the Windows
Vista Home Premium and Ultimate
C
Editions only.
C - 4 Specifications

Power Management

Supports Wake on LAN
Supports Wake on USB
Power
Full Range AC/DC Adapter – AC in 100 -
240V, 50 - 60Hz DC Output 19V, 11.6A or
19V, 12.2A (220 Watts)
Easy Changeable Polima Smart Lithium-
Ion 4650mAH Main Battery
Physical Dimensions & Weight
439mm (w) * 299mm (d) * 44mm (h)
Around 4.9kg with Battery and ODD

Environmental Spec

Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%

Optional

Super Multi Drive Module
Blu-Ray Combo Drive Module
Intel® WiFi Link 5300/5100 Series (3*3/
1*2 - 802.11a/g/n) Wireless LAN PCIe
Interface Mini-Card Module
3rd Party 802.11b/g Wireless LAN PCIe
Interface Mini-Card Module
Bluetooth 2.1 + EDR (Enhanced Data
Rate) Module (Factory Option)
2.0M or 3.0M Pixel USB 2.0 PC Camera
Module (Factory Option)
Fingerprint Reader Module (Factory
Option)
Mini-Card TV Tuner Module with USB
Interface (Factory Option)
