Summary of Contents for EUROCOM Notebook V12.3.10

Page 1 V12.3.10...
Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4 Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 6: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 7: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 8: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 9 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 10: Power Safety
Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply.
Page 11: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 12: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 13: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 14: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 15 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 16 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 17: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 18 Preface...
Page 19: Table Of Contents
Preface Contents Notice .................I System Map: LCD Panel Open & Top View ....1-6 FCC Statement ..............III LED Indicators ...............1-7 FCC RF Radiation Exposure Statement: ......IV Touch Sensor Instant Keys ..........1-8 EuP-Standby and Off Mode Power Consumption Keyboard ................1-9 Statement: ...............
Page 20 Preface DVD Regional Codes ............2-5 Battery Information ............3-11 Multi-In-1 Card Reader ..........2-6 Conserving Battery Power ...........3-12 ExpressCard Slot ............2-7 Battery Life ..............3-13 Inserting and Removing ExpressCards ......2-7 New Battery ..............3-13 Audio Features ...............2-8 Recharging the Battery with the AC/DC Adapter ..3-13 Setup for 5.1 or 7.1 Surround Sound ......2-9 Proper handling of the Battery Pack ......3-14 Setup for Audio Recording ..........2-11...
Page 21 Preface USB 3.0 ................4-7 Advanced Chipset Control (Advanced Menu) ....5-8 MEI Driver ..............4-7 Bluetooth Power Setting (Advanced Menu > Audio ................4-7 Advanced Chipset Control) ...........5-9 Optional Drivers ............4-9 SATA Mode (Advanced Menu) ........5-9 PC Camera ..............4-9 Power On Boot Beep (Advanced Menu) .......5-9 Wireless LAN ..............4-9 Battery Low Alarm Beep (Advanced Menu) ....5-9 Fingerprint Reader Module ..........4-9...
Page 22 Preface Upgrading the System Memory (RAM) ......6-11 Security Modules (Fingerprint & TPM) ......7-43 Upgrading the Video Card ...........6-23 Fingerprint Reader Module ..........7-44 Fingerprint Reader Driver Installation ......7-44 Modules AuthenTec TrueSuite Application .......7-45 Bluetooth Module ............7-55 Overview ................7-1 3rd Party Bluetooth Combo Driver Installation ...7-57 Setting Up SATA RAID or AHCI Mode ......7-2 3rd Party Bluetooth &...
Page 23 Preface Basic Hints and Tips ............8-2 USB 2.0/1.1 Ports* ............A-5 Backup and General Maintenance .........8-3 USB 3.0 Port ..............A-5 Viruses ................8-4 Control Center Upgrading and Adding New Hardware/Software ..8-5 Problems & Possible Solutions ........8-7 Overview ...............B-1 Bluetooth Connection Problems ........8-17 NVIDIA Video Driver Controls Intel®...
Page 24 Preface HDMI Audio Configuration ........C-18 Security .................D-4 Audio Setup for HDMI ..........C-19 Operating System ............D-4 HDMI Notes ............... C-21 Design Feature ..............D-4 HDMI Video Configuration ........C-21 Power Management ............D-4 HDCP Status ..............C-22 Power ................D-4 NVIDIA 3D Shutter Glasses Kit ........ C-23 Environmental Spec ............D-4 Stereoscopic 3D Hardware Setup .......
Page 25: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 26: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 27: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types (only Model B computers support 3D). Note that your model may appear slightly different from those pictured in this manual. Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals.
Page 28: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 7 (with Service Pack 1 in- stalled) operating system is supported.
Page 29: System Startup
Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. 3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 30: System Map: Lcd Panel Open & Top View
Quick Start Guide System Map: LCD Panel Open & Top View Figure 1 - 2 LCD Panel Open  & Top View 1. Built-In PC Camera Wireless Device 2. Built-In Microphone Operation Aboard 3. LCD Aircraft 4. LED Status Indicators The use of any portable elec- 5.
Page 31: Led Indicators
Quick Start Guide LED Indicators The two sets of LED indicators (LED Status Indicators and LED Power Indicators) display helpful informa- tion about the current status of the computer. Icon Color Description Icon Color Description Blinking Hard Disk Activity Orange DC Power is Plugged In Blue Number Lock is Activated...
Page 32: Touch Sensor Instant Keys
Quick Start Guide Touch Sensor Instant Keys Press the Touch Sensor Instant Keys on the computer to toggle the appropriate function on/off. When a module is powered on the appropriate icon will be highlighted blue. Icon Description Mute Toggle Bluetooth Module (optional) Power Toggle Wireless LAN Module (optional) Power Toggle PC Camera Module Power Toggle Volume Control (Press and hold your finger at either end...
Page 33: Keyboard
Quick Start Guide Keyboard  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 5, on page 1 - 13 for full function key combination details.
Page 34: Keyboard Led
Quick Start Guide Keyboard LED Press Fn plus the key to toggle the keyboard LED on/off. The keyboard LED may be configured using the Fn + key combination outlined in the table below. In addition press Fn plus the key to launch the keyboard backlight application to configure the settings (see overleaf).
Page 35 Quick Start Guide Keyboard Backlight Application The keyboard Backlight application can be accessed by pressing the Fn plus key. Click the Help button in the application to display the configuration keys. • Click the Custom button to display the three sections of the keyboard which may be configured. •...
Page 36: Effects Buttons & Help
Quick Start Guide Effects Buttons & Help LED Effects Buttons Random Color Up/Down Wave Dancing Effect Breathing (All Colors) Tempo Beat Cycle (Colors as Selected in RGB) Custom Mode - Display & Configure Flashing Keyboard Sections & Colors  Illumination Keys Note that the keyboard illumi- nation (increase/decrease) keys may be used to config-...
Page 37 Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Visual in- dicators (see the table below) are available when the Hot Key driver is installed (see “Hot Key”...
Page 38: Control Center
Quick Start Guide Control Center Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and en- ables you to quickly turn modules on/off.
Page 39: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 5 Front & Rear Views 1. LED Power Indica- tors 2. Express Card Slot 3. Multi-In-1 Card Reader 4. DC-In Jack Appendix A for a more detailed description of the ports &...
Page 40: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 6 Right View 1. Line-In Jack 2. S/PDIF-Out Jack 3. Microphone-In Jack 4. Headphone-Out Jack 5. 2 * USB 2.0 Ports 6. Sub Woofer  7. Security Lock Slot USB Ports Appendix A for a more Note that the connections to the USB ports only fit one way, do not force them.
Page 41: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 7 Left View 1. DVI-Out Port 2. RJ-45 LAN Jack 3. HDMI-Out Port 4. Display Port 5. 2 * USB 3.0 Ports 6. Combined eSATA/ Powered USB 3.0  Port 7.
Page 42 Quick Start Guide   Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 43: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 8 Bottom View 1. Fan Outlet/Intake 2. Component Bay Cover 3. Battery 4. HDD Bay  Overheating  To prevent your comput- er from overheating make Battery Information sure nothing blocks the Always completely discharge, then fully charge, a new battery before using it.
Page 44 Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 45: Video Features
Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 7 (see over). For more detailed video information see “NVIDIA Video Driver Controls” on page C - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.
Page 46: Screen Resolution
Quick Start Guide Screen Resolution  Video Options Note that card types, specifi- cations and drivers are sub- ject to continual updates and changes. Check with your service center for the latest details on video cards sup- ported. Figure 1 - 10 - Screen Resolution 1 - 22 Video Features...
Page 47: Nvidia Control Panel
Quick Start Guide NVIDIA Control Panel You can access the NVIDIA Control Panel as follows: Click Start, and click Control Panel. Click NVIDIA Control Panel (Figure 1 - 11) - In the Appearances and Personalization category. “NVIDIA Video Driver Controls” on page B - 1 for full details on control panels etc.
Page 48: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 20) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 49: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • Multi-In-1 Card Reader •...
Page 50: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive  The hard disk drive(s) is(are) used to store your data in the computer. The hard Power Safety disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 51: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page D - 3).
Page 52: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 53: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 54: Multi-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer Multi-In-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 55: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot  The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 56: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek HD Audio Manager icon in the notifi- The sound volume level cation area/control panel (right-click the taskbar notification area icon to bring up is set using the volume...
Page 57: Setup For 5.1 Or 7.1 Surround Sound
Storage Devices, Mouse, Audio & Printer Setup for 5.1 or 7.1 Surround Sound  To setup your system for 5.1 or 7.1 surround sound you will need to connect the au- dio cables to the Headphone-Out, Line-In, Microphone-In jack and S/PDIF-Out THX Audio &...
Page 58 Storage Devices, Mouse, Audio & Printer Plug the front speaker cables into the Headphone-Out Jack. Plug in the other cables (you may require an adapter to connect each cable to the appropriate jack e.g a stereo mini to dual RCA adapter) from your speakers as follows: •...
Page 59: Setup For Audio Recording
Storage Devices, Mouse, Audio & Printer Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the taskbar icon and select Sound Manager).
Page 60: Audio Notes For Fn + 5
Storage Devices, Mouse, Audio & Printer Audio Notes for Fn + 5 This computer features an Fn +5 key combination to toggle between standard audio and enhanced audio. Note the following which applies to software mode audio con- figuration through the computer’s internal speakers only (this does not apply to surround sound when configured through external Quadrophonic, 5.1 or 7.1 speaker systems): •...
Page 61: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse  The TouchPad is an alternative to the mouse; however, you can also add a mouse to TouchPad Scrolling your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 62: Gestures And Device Settings
Storage Devices, Mouse, Audio & Printer Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the Touchpad to perform specific actions to manipulate doc- uments, objects and applications.
Page 63 Storage Devices, Mouse, Audio & Printer Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the TouchPad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 11 tinuous motion).
Page 64 Storage Devices, Mouse, Audio & Printer Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the TouchPad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Page 65: Power Management
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the LCD and hard disk drive) or the whole system.
Page 66: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 67: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 68: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 69 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 70: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 71: Hibernate
Power Management Hibernate  Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Silent Mode power failure occurs the system can restore your work from the hard disk; if a power You can use Silent failure occurs when work is saved only to memory, then the work will be lost.
Page 72: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 73: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to send the computer to Power Status Icon Color...
Page 74: Power Conservation Modes
Power Management Power Conservation Modes  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
Page 75: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 76: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 77: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 78: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances. • DO NOT expose the battery to fire or high temperatures, it may explode. Caution • DO NOT connect the metal terminals (+, -) to each other. Danger of explosion if battery is incorrectly re- ...
Page 79: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 80 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 81 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 82 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 83: Sli Multi Gpu Configuration & Power
Power Management SLI Multi GPU Configuration & Power  Note that due to the high power and system demands created by enabling an SLI SLI Configuration & configuration, you should not power the system using the battery only and you Multiple Displays will require identical (300W) dual power adapters, connected to a power con- verter box, to power the system..
Page 84 Power Management 3 - 20...
Page 85: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities  Driver Installation & This chapter deals with installing the drivers and utilities essential to the operation or Power improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.
Page 86: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 87 Drivers & Utilities Driver for Windows 7 with Service Pack 1* Intel Rapid Storage Technology Chipset Page 4 - 6 Page 7 - 9 (for RAID & AHCI mode Hard Disk Drives) Video (VGA) Page 4 - 6 PC Camera Module Page 7 - 15 Page 4 - 7 Wireless LAN Module...
Page 88: Manual Driver Installation
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click the Browse CD/DVD button in the Drivers In- If you wish to update/reinstall individual drivers it staller application and browse to the executable file in may be necessary to uninstall the original driver.To do the appropriate driver folder.
Page 89: User Account Control
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue/Al- ing the installation procedure (other than when out- low, and follow the installation procedure as directed.
Page 90: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Chipset Insert the Device Drivers & Utilities + User’s Manual 1. Click 1.Install Chipset Driver > Yes. disc and click Install Drivers (button), or Option Driv- 2. Click Next > Yes > Next > Next. ers (button) to access the Optional driver menu.
Page 91: Lan
Drivers & Utilities Hot Key 1. Click 3.Install LAN Driver > Yes. 1. Click 6.Install Hotkey AP > Yes. 2. Click Next > Next. 2. Click Install Drivers and Software (button). 3. Click Finish > Finish to restart your computer. 3.
Page 92 Drivers & Utilities After installing the audio driver the system will not re-  turn to the Drivers Installer screen. To install any of the optional drivers, eject the Device Drivers & Utili- Windows Update ties + User’s Manual disc and then reinsert it (or dou- ble-click the disc icon in My Computer), and click After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up-...
Page 93: Optional Drivers
Drivers & Utilities Optional Drivers RAID Setup “Setting Up SATA RAID or AHCI Mode” on See the pages indicated for the driver installation pro- page 7 - cedures for any modules included in your purchase op- tion. PC Camera “PC Camera Module” on page 7 - Wireless LAN “Wireless LAN Module”...
Page 94 Drivers & Utilities 4 - 10...
Page 95: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
Page 96: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) If you enable the Boot-time Diagnostic Screen in the Setup Utility, each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.
Page 97: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 98: The Setup Utility
BIOS Utilities The Setup Utility  The Aptio Setup Utility tells the system how to configure itself and manage basic BIOS Settings features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 during the POST. The prompt malfunction.
Page 99: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
Page 100: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 101: Sata Port # (Main Menu)
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA ports. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
Page 102: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting. 5 - 8 Advanced Menu...
Page 103: Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)
BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)  You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is SATA Mode started up or restarted.
Page 104: Security Menu
BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
Page 105: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Aptio Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to Password Warning set a Password on Boot (see below).
Page 106: Trusted Computing (Security Menu)
BIOS Utilities Trusted Computing (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select Trusted Computing and press En- ter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu (see “Trusted Platform Mod- ule”...
Page 107: Tpm State (Security Menu > Tpm Support Enabled)
BIOS Utilities TPM State (Security Menu > TPM Support Enabled) Select TPM State, press Enter and select Enable to change the TPM state to en- abled. You will then need to press F4 to save the changes and restart the computer. Figure 5 - 6 TPM State (Enabled) As the computer restarts press F2 to enter the BIOS again and go to the TPM Con-...
Page 108: Pending Tpm Operation (Security Menu > Tpm Support & Tpm State Enabled)
BIOS Utilities Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer.
Page 109: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 8 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
Page 110: Boot Option Priorities (Boot Menu)
BIOS Utilities Boot Option Priorities (Boot Menu) Use the arrow keys to move up and down the menu, and go to either CD/DVD ROM Drive BBS Priorities or Hard Drive BBS Priorities and use the F5 and F6 keys to move the device’s boot priority up and down the list (the selected device will be highlighted in white).
Page 111: Save & Exit Menu
BIOS Utilities Save & Exit Menu Figure 5 - 9 Save & Exit Menu Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 112 BIOS Utilities 5 - 18...
Page 113: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 114: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 115: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Before removing the battery disconnect the AC/ DC adapter from the computer first. Please check with your service representative...
Page 116: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Locate the hard disk bay cover and remove screws & Remove the hard disk bay cover Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install any new optical device.
Page 117: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s)  The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page D - 3).
Page 118 Upgrading The Computer Removing the Hard Disk(s) from the Primary HDD Bay  Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat- tery. RAID Hard Disks Locate the hard disk bay cover and remove screws &...
Page 119 Upgrading The Computer Remove screws from the hard disk assembly. Carefully pull up the tab to disconnect the hard disk cable Carefully (the HDD case edges may be sharp) apply pressure using two fingers at & points Lift the assembly out of the bay and separate the hard disk board from the case by pulling on the tab Figure 6 - 4...
Page 120 Upgrading The Computer Remove screws (depending on how many hard disks you have installed in the assembly). Separate the hard disk(s) & from the case and mylar insulation cover 10. Reverse the process to install any new disk(s) and do not forget to install the insulation plate (onto the upper hard disk), screws, cables and covers (pay careful attention to the orientation of the hard disks in the case).
Page 121 Upgrading The Computer Removing the Hard Disk from the Secondary HDD Bay Remove the battery (the Secondary hard disk bay is located under the battery). Remove screws from the hard disk assembly. Grip the tab and slide the hard disk assembly in the direction of the arrow Lift the hard disk assembly out of the compartment.
Page 122 Upgrading The Computer Remove the screws to release the hard disk from the case Reverse the process to install any new hard disk(s). Figure 6 - 7 Secondary HDD Case Removal 6 - 10 Upgrading the Hard Disk Drive(s)
Page 123: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR III (DDR3) type memory modules (see “Memory” on page D - The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 124 Upgrading The Computer Turn the computer over, open the Lid/LCD, and carefully (a cable is connected to the underside of the LED cover module) unsnap up the LED cover module from point on the right. Figure 6 - 9 LED Cover Module Removal Lift up the LED cover module and disconnect cable...
Page 125 Upgrading The Computer Remove screws from the keyboard. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable or keyboard LED cable. Figure 6 - 11 Keyboard Screws Disconnect the keyboard ribbon cable from the locking collar socket , and the keyboard LED cable from its locking collar socket...
Page 126 Upgrading The Computer Remove the keyboard shielding plate Figure 6 - 13 Keyboard Shielding Plate Removal  Contact Warning Be careful not to touch 10. Gently pull the two release latches ( & on the sides of the memory socket in the metal pins on the the direction indicated below.
Page 127 Upgrading The Computer 11. The RAM module will pop-up, and you can remove it.  Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance.
Page 128 Upgrading The Computer 15. Replace the screws and shielding plate. 16. Replace the keyboard and make sure you reconnect the keyboard cable. 17. When reconnecting the keyboard LED cable , twist the cable slightly so that the gold colored contact is facing upwards to fit inside the connector. Make sure you tuck the cable into the recess in the shield plate to avoid trapping it between the keyboard and the shielding plate.
Page 129 Upgrading The Computer 18. Reconnect the LED Module cable (see Figure 6 - 10). 19. Snap the LED cover module down at the top of the module at points & 20. Push the LED cover module down on the left side at point , and then slide the module to the right (as illustrated) and snap down to secure it in place.
Page 130: Remove Screws
Upgrading The Computer Removing the Secondary System Memory (1 memory socket) Turn off the computer, and turn it over and remove the battery. Remove screws and component bay cover Figure 6 - 18 Component Bay Cover Removal Carefully disconnect CPU fan cables &...
Page 131 Upgrading The Computer Carefully (it may be hot) lift up the heatsink off the computer. Figure 6 - 20 CPU Heatsink Removal Remove screws from the fan unit, disconnect the fan cable , and lift the fan unit off the computer. Figure 6 - 21 Fan Removal Upgrading the System Memory (RAM) 6 - 19...
Page 132: Figure
Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in  the direction indicated below. The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the module’s connecting...
Page 133: Figure
Upgrading The Computer 11. Replace the fan unit above the RAM module slot and replace screws reconnect the cable Figure 6 - 23 Fan Unit Screws & Cable 12. Insert the heatsink (make sure not to trap or catch the plastic VGA heat sink tab under the CPU heat sink when inserting it).
Page 134 Upgrading The Computer 13. Tighten the CPU heat sink screws in the order indicated on the label (i.e. remove screw first, and lastly remove screw 14. Replace the component bay cover and screws. Figure 6 - 25 Heatsink Screws & Cables 6 - 22 Upgrading the System Memory (RAM)
Page 135: Upgrading The Video Card
Upgrading The Computer Upgrading the Video Card  If you intend to upgrade or add another video card follow the procedures outlined Warranty Warning here. However please check with your service representative first to make sure your computer can support more than one video card, and that you are not going to void Please check with your service representative...
Page 136 Upgrading The Computer The video card(s) will be visible at point on the mainboard (two video cards are  pictured). Carefully disconnect the video card fan cable(s) , and remove screws Heat Sink Screws Remove the video card fan(s) (two video card fans are pictured here). Remove screws from the heat sink in the order indicated on the heat Make sure you remove...
Page 137 Upgrading The Computer Carefully pull the tab and lift at points & to disconnect the heat sink from  the VGA assembly (a single unit is pictured). Remove the heat sink unit(s) (two heat sink units are pictured here). Caution The heat sink, and video card area in general, contains parts which are...
Page 138 Upgrading The Computer 10. Carefully lift up the mylar sticker cover(s) at point (two covers are pictured).  11. Remove the mylar sticker cover(s) and only use a flat-headed screwdriver (do not try to use any other screwdriver type here) to remove screws &...
Page 139 Upgrading The Computer Installing a New Video Card  Do not forget to replace the master and slave cable if you are replacing two video cards (see Figure 6 - 29 on page 6 - 26). Contact Warning Prepare to fit the video card into the slot by holding it at about a 30° angle. Be careful not to touch the metal pins on the VGA card’s connecting...
Page 140 Upgrading The Computer Fit the connectors firmly into the socket, straight and evenly. DO NOT attempt to push one end of the card in ahead of the other. Figure 6 - 31 Video Card Insertion Procedure The card’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the socket as it will go (none of the gold colored contact should be showing).
Page 141 Upgrading The Computer Secure the card with screws & and mylar sticker cover(s)  Hold the heatsink by the tab , and at points & , and insert it back on the card as pictured. Heat Sink Screws Secure the screws in the order indicated on the heat sink unit label (and heat sink itself).
Page 142 Upgrading The Computer 10. Reinsert the fans and secure with screws and fan cable 11. Replace the component bay cover and screws Figure 6 - 33 Fan Screws & Cables and Component Bay Cover Screws  SLI Configuration & Power This computer features an NVIDIA Scalable Link Interface (SLI) that improves graphic quality and performance by combining dual NVIDIA GPUs (two video cards are required) in a single system.
Page 143: Modules
Modules Chapter 7: Modules Overview This chapter contains information on the various modules (some of which are op- tional) which may come with your computer, depending on the configuration pur- chased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 144: Setting Up Sata Raid Or Ahci Mode
Modules Setting Up SATA RAID or AHCI Mode  AHCI Mode RAID Hard Disks Advanced Host Controller Interface (AHCI) is an interface specification that allows All hard disks in a RAID the storage driver to enable advanced serial ATA features such as Native Command should be identical (the Queuing (for maximum hard disk efficiency and performance).
Page 145 Modules RAID Level Description Table 7 - 1 RAID Levels Two Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive.
Page 146: Sata Raid Setup Procedure (Bios)
Modules SATA RAID Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode" and press Enter (see page • Select “RAID Mode”. Go to the Boot menu. Set the DVD-ROM Drive (make sure the Microsoft Windows 7 OS DVD is inserted) as the first device in the boot order from the Boot menu (see “Boot Menu”...
Page 147: Raid Setup (Intel Matrix)
Modules RAID Setup (Intel Matrix) As the computer starts up press Ctrl + i to enter RAID configuration menu. Figure 7 - 1 Intel(R) Rapid Storage Technology Option ROM Select 1.Create RAID Volume and press Enter. Type the RAID volume name and then press Tab or Enter to advance to the next field.
Page 148 Modules Press Enter and the system will select the physical disks to use. Press Enter and select (if applicable) the Strip Size (best set to default). Press Enter and select the Capacity size (best set to default). Press Enter to select Create Volume. Press Enter to create the volume, and confirm the selection by pressing Y.
Page 149 Modules 12. Make sure the Windows 7 OS DVD is in the DVD drive. and as the computer starts up it will automatically boot from the Windows 7 OS DVD (you will be prompted to press a key to boot from the DVD). 13.
Page 150 Modules Make sure your USB Flash drive or external USB hard disk is attached to one of the USB ports on the computer. Click “I accept the license terms” tickbox and click Next. Click Custom (advanced). Click to select Load Driver when the “Where do you want to install Windows?” screen appears.
Page 151: Intel Rapid Storage Technology
Modules Intel Rapid Storage Technology  The Intel Rapid Storage Technology application provides high-performance SATA and SATA RAID capabilities. Install the Intel Rapid Storage Technology Intel® Control Center application to support your RAID system or SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)”...
Page 152 Modules Intel® Rapid Storage Technology for RAID Systems Intel® Rapid Storage Technology application displays status information on your RAID configuration. Run the Intel® Rapid Storage Technology enterprise appli- cation from the Intel item in the All Programs menu. When the Intel® Rapid Storage Technology enterprise application is launched the system will open the Status window.
Page 153 Modules Intel® Rapid Storage Technology Help  If a hard drive member of a RAID volume is reported as “Degraded” or “Failed” it may be possible to recover the volume. If the volume cannot be restored then you Help will need to recreate the RAID volume and restore the data from a back up. Click the Click the Help (or Help menu (or press F1) for instructions on how to recover or recreate RAID Vol-...
Page 154: Raid Volume Data Verification And Repair
Modules RAID Volume Data Verification and Repair The RAID volume data verification process identifies any inconsistencies or bad data on a RAID 0, RAID 1 or RAID 5 volume. The table outlines what occurs for each RAID level: RAID Verify Verify &...
Page 155 Modules Verifying and Repairing RAID Volume Data Initializing, Before verifying the volume data you will need to initialize the volume. Run the Intel® Rapid Storage Technology enterprise application from the Intel item in the All Programs menu. Click the volume icon and click Initialize in Volume Properties. Click Yes (button) to begin the process.
Page 156 Modules After the initialization process you will need to verify the volume. Click the volume icon and click Verify, in Volume Properties. Click Verify (button) to begin the process. The completion percentage will be listed under Information. Verify Figure 7 - 6 ®...
Page 157: Pc Camera Module
Modules PC Camera Module  Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination or Touch Sensor Instant Key to toggle power to the PC Cam- Driver Information era module.
Page 158: Pc Camera Driver Installation
Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Webcam Driver > Yes. 4. Click Finish to restart the computer. Click Next >...
Page 159: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 160 Modules Figure 7 - 7 Audio Setup for PC Camera Right-click 7 - 18 PC Camera Module...
Page 161 Modules Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup”...
Page 162 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 163 Modules Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 164 Modules Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Page 165: Wireless Lan Module
Modules Wireless LAN Module  If you have included an Intel® or 3rd Party 802.11b/g/n WLAN module in your Wireless Device purchase option, make sure that the Wireless LAN module is on before installing the Operation Aboard driver. Aircraft The use of any portable Use the Fn + F11 key combination or Touch Sensor Instant Key to toggle electronic transmission de-...
Page 166: Intel® Wi-Fi Link Series Driver Installation
Modules Intel® Wi-Fi Link Series Driver Installation  If you see the message “Found New Hardware” click Cancel to close the window. Intel(R) PROSet/ 1. Make sure the module is powered on, then insert the Device Drivers & Util- Wireless ities + User’s Manual disc into the CD/DVD drive.
Page 167: Connecting To A Wireless Network In Windows 7
Modules Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then double-click an access point to con- Network and nect to or click to Open Network and Sharing Center if you do not see a network Sharing Center you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net-...
Page 168 Modules You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 169 Modules Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.
Page 170 Modules Intel My WiFi Configuration ®  Intel® My WiFi Technology uses your WLAN (for Intel WLAN modules only) module to allow you to connect up to eight other WiFi enabled devices (e.g. digital Intel® My WiFi Help cameras, other computers, cell phones, handheld devices etc.) to your computer To get help on Intel®...
Page 171: Intel® My Wifi Configuration
Modules Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the notification area icon Click Enable (on the first run of the program there will be no connected...
Page 172 Modules Click Start and click Control Panel. Click Network and Sharing Center (Network and Internet). Click Change adapter settings. Figure 7 - 13 Network and Sharing Center Click Change adapter settings 7 - 30 Wireless LAN Module...
Page 173 Modules Right-click Wireless Network Connection and select Properties. Figure 7 - 14 Network Connections Right-click Wireless Network Connection and select Proper- ties. Wireless LAN Module 7 - 31...
Page 174 Modules Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Connection under Home networking connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Figure 7 - 15 Connection.
Page 175 Modules 10. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the notification area icon 11. Click Profiles Figure 7 - 16 Intel®...
Page 176 Modules 12. Click Profiles, click Intel Wireless PAN and click Edit or New (Note that all preset settings may not be editable - see sidebar). Figure 7 - 17 Profiles  Profile Settings 13. You can change the Profile Name and Network Name to your personal Profiles that are preset preferences in General (tab).
Page 177 Modules 14. Click Security (tab). 15. Change the Security Type to WEP and the Encryption Type to 64bit. 16. Enter a password (8 characters long) in the Password box. Figure 7 - 19 Intel® My WiFi Profile Settings - Security Wireless LAN Module 7 - 35...
Page 178 Modules 17. Click Sharing (tab). 18. It is recommended that the Filter Network Traffic and DHCP and DNS Server are Disabled. Figure 7 - 20 Intel® My WiFi Profile Settings - Sharing 7 - 36 Wireless LAN Module...
Page 179 Modules 19. Click Advanced (tab). 20. It is recommended that the Default Channel is set to Channel 1, 6 or 11. 21. Click OK to save the settings. Figure 7 - 21 Intel® My WiFi Profile Settings - Advanced Wireless LAN Module 7 - 37...
Page 180 Modules 22. Double-click Wireless Network Connection in Network Connections. 23. Click Details to display the Network Connection Details. Figure 7 - 22 Wireless Network Connection Details 7 - 38 Wireless LAN Module...
Page 181 Modules 24. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the notification area icon 25. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Page 182: Intel Wlan & Bluetooth Combo Module High-Speed Data Transfer Configuration
Modules Intel WLAN & Bluetooth Combo Module High-Speed Data Transfer Configuration You will need to configure the following settings to enable high-speed wireless data transfer as supported by Intel Wireless LAN & Bluetooth Combo modules (note this information applies to Intel WLAN & Bluetooth Combo modules only). Go the Windows control panel and double-click Device Manager (in Hardware and Sound under Devices and Printers).
Page 183 Modules Click Network adapters to expand the sub-menu. Double-click the Intel WiFi Link ..module. Click Advanced (tab). Click 802.11n Channel Width for band 2.4 under “Property:”. Click the pull-down menu under “Value:” Click to select Auto. Click OK and close the control panels. Figure 7 - 25 Intel WiFi Link Properties...
Page 184: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 185: Security Modules (Fingerprint & Tpm)
Modules Security Modules (Fingerprint & TPM)  The encrypted channel between the Trusted Platform Module security chip (see Password Warning “Trusted Platform Module” on page 7 - 70) and the fingerprint reader with Au- thenTec TrueSuite software (see “Fingerprint Reader Module” on page 7 - If you set passwords for provides a high level of security for your computer.
Page 186: Fingerprint Reader Module
Modules Fingerprint Reader Module The fingerprint reader module provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. Fingerprint Reader Driver Installation 1.
Page 187: Authentec Truesuite Application
Modules AuthenTec TrueSuite Application  The AuthenTec TrueSuite application is used in conjunction with your fingerprint reader to enroll fingerprints and manage settings etc. Fingerprint Enrollment User Enrollment Note that it is strongly rec- Click Start > All Programs > AuthenTec TrueSuite. ommended that you enroll Click Yes when you have identified your fingerprint sensor ( Fingerprint...
Page 188 Modules You will be prompted to select another finger for enrollment (it is recommended  that you enroll a number of fingers - see sidebar). Click the button to continue once you have enrolled a number of fingerprints. Help Enter the required information and click the button to register your software, or click to register later.
Page 189 Modules Settings Click the Settings button on the menu bar to access the personalization settings for AuthenTec TrueSuite. Here you can choose to enable/disable Website Log On, QuickLaunch, Fast User Switching and the desktop icon. You can also select the Theme and export/import identities.
Page 190 Modules Windows Log On Windows log on allows you to gain access to your computer by swiping your finger across the fingerprint reader sensor. Use the Biometric Devices control panel (in the Hardware & Sound category) in Windows to turn Biometrics on/off when re- quired.
Page 191 Modules Website Log On Use a fingerprint swipe to log on to websites to help you avoid having to remember user names and passwords across multiple websites (browsers supported are Internet Explorer, Firefox and Chrome). Registering a Website Use your web browser to navigate to the website required. Enter your user name and password and sign in to the website.
Page 192 Modules QuickLaunch QuickLaunch allows you to drag and drop icons (which represent websites, folders, applications and/or computer actions) to any enrolled finger and then swipe your fin- ger to launch the icons assigned to that finger. Click Start > All Programs > AuthenTec TrueSuite. Click Select Category (button) to group icons if required.
Page 193 Modules Adding a Website to QuickLaunch Click Start > All Programs > AuthenTec TrueSuite. Click the Add Website button on the menu bar and the dialog box will be displayed. Enter the website URL, name, icon and category as required. Click Save and an icon will be associated with the selected website.
Page 194 Modules Dock View Dock View displays the website icons across the bottom of the screen. Each icon wiLl have an associated web card which displays the website information, user name and password etc. This information may be edited or deleted as required. Figure 7 - 35 Dock View Editing a Web Card...
Page 195 Modules Exporting and Importing Your Identity You can export your identity to backup your information, or to move it to another computer. Exporting Your Identity Click Start > All Programs > AuthenTec TrueSuite. Click the Settings button on the menu bar. Click Export My Identity.
Page 196 Modules AuthenTec KeepSafe The KeepSafe folder is an encrypted area assigned on your hard drive that allows you to store files and folders to be protected by fingerprint protection. The folder will appear on your desktop (if selected in the Personalization Settings) and in My Computer, but will not be visible to other users of your computer.
Page 197: Bluetooth Module
Modules Bluetooth Module  If your purchase option includes the Combination Wireless LAN & V3.0 Blue- Wireless Device tooth module (either Intel® Centrino Advanced-N 6230 or 3rd Party) then install Operation Aboard the driver as instructed. Aircraft If your purchase option includes a standard V2.1 Bluetooth module, then the op- The use of any portable electronic transmission de- erating system’s Bluetooth Devices control panel is used to configure the Bluetooth...
Page 198 Modules Use the Fn + F12 key combination or Touch Sensor Instant Key to toggle power to the Bluetooth module. When the Bluetooth module is powered on the LED will be highlighted and the indicator will briefly be displayed. • For 3rd party Bluetooth V2.1 +EDR modules see “Standard Bluetooth Con- figuration in Windows 7”...
Page 199: 3Rd Party Bluetooth Combo Driver Installation
Modules 3rd Party Bluetooth Combo Driver Installation  Note this driver is required only for the combo Bluetooth and WLAN module only. High Speed Bluetooth 1. Before installing the driver make sure the Bluetooth module is powered Data Transfer on (use Fn + F12 key combination), then insert the Device Drivers & Utili- The Combination Wire- ties + User’s Manual disc into the CD/DVD drive.
Page 200: 3Rd Party Bluetooth & Wlan Combo Settings
Modules 3rd Party Bluetooth & WLAN Combo Settings  This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Make sure the Bluetooth module is powered on. Resuming From Sleep Access the My Bluetooth application from Bluetooth in the Programs/All Mode Programs menu.
Page 201 Modules Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 38 General Settings Bluetooth Module 7 - 59...
Page 202 Modules Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 39 File Transfer Settings 7 - 60 Bluetooth Module...
Page 203: 3Rd Party Bluetooth Networking Setup
Modules 3rd Party Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module only. Make sure the Bluetooth module is powered on. Access the My Bluetooth application from Bluetooth in the Programs/All Programs menu. Click My Bluetooth Settings (see Figure 7 - 37 on page 7 - 58).
Page 204: 3Rd Party Bluetooth & Wlan Combo Module Configuration
Modules 3rd Party Bluetooth & WLAN Combo Module Configuration  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Module & Make the device discoverable (to do this check your device documentation). Resuming From Sleep Mode To Turn the Bluetooth Module On...
Page 205 Modules You will then be presented with a menu of options to select from. Figure 7 - 42 Bluetooth Device Options Click the appropriate button to connect to the device. Bluetooth Module 7 - 63...
Page 206 Modules You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection. Figure 7 - 43 Bluetooth Pairing Code &...
Page 207: Intel Bluetooth Combo Driver Installation
Modules Intel Bluetooth Combo Driver Installation  Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Page 208: Standard Bluetooth Configuration In Windows 7
Modules Standard Bluetooth Configuration in Windows 7  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 209 Modules To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con- nections.
Page 210 Modules Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 46 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 211 Modules To Change Settings for the Bluetooth Device  Click the notification area icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 212: Trusted Platform Module
Modules Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.
Page 213: Enabling & Activating Tpm
Modules Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu. Select Trusted Computing and press Enter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu.
Page 214 Modules Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer. Figure 7 - 50 Pending TPM operation (Enable Take...
Page 215: Trusted Platform Module (Tpm) Driver Installation
Modules Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver (if you do not do see the note below). 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Page 216: Initializing Tpm
Modules Initializing TPM Run the application from the Infineon Security Platform Solution > Manage Security Platform item in the Start > Programs menu. Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
Page 217 Modules Choose the Security Platform Features you want to use by clicking the  appropriate tickbox. Enter a Basic User Password (and re-type to confirm it) and click Next. Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use the Security Platform Fea- tures.
Page 218: Infineon Security Platform Settings Tool
Modules Infineon Security Platform Settings Tool  The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
Page 219 Modules User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
Page 220 Modules Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion. Figure 7 - 56 Infineon Security Platform Settings...
Page 221 Modules Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 57 Infineon Security Platform Settings Tool (Migration) Trusted Platform Module 7 - 79...
Page 222 Modules Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 58 Infineon Security Platform Settings Tool (Password Reset) 7 - 80 Trusted Platform Module...
Page 223 Modules BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
Page 224 Modules Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 60 BitLocker Drive Encryption 7 - 82 Trusted Platform Module...
Page 225 Modules Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 61 Infineon Security Platform Settings Tool (Advanced) Trusted Platform Module 7 - 83...
Page 226: Thx Trustudio Pro Audio
Modules THX TruStudio Pro Audio  Install the THX TruStudio AP to allow you to configure the audio settings to your THX TruStudio & requirements for the best performance in games, music and movies. Speaker Configuration THX TruStudio AP Installation Note that THX TruStu- 1.
Page 227: Thx Trustudio Pro Activation
Modules THX TruStudio Pro Activation  On the first run of THX TruStudio Pro you will need to activate the application. THX Audio & HDMI To activate the application you will need to be connected to the internet. Double-click the THX Activate icon on the desktop and click the Activate Note that the THX audio button.
Page 228 Modules THX Control Panel Each control has an On/Off button to allow you to enable/disable the control, and most controls feature a slider to adjust the levels (the subwoofer may be turned on/ off). Menu Figure 7 - 63 THX TruStudio Pro Controls •...
Page 229 Modules THX TruStudio Pro & HDMI When you connect an HDMI display to the HDMI-Out port, the THX Tru Studio Pro controls will be disabled. A warning box will pop-up and will prompt “Do you want to select another audio device now?”.
Page 230: Irst Driver
Modules IRST Driver Install the Intel Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - 9) or if you have set up your hard disks in a RAID configuration (“Setting Up SATA RAID or AHCI Mode”...
Page 231: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 232: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 233: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 234: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 235: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 236 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 237: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 238 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 239 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 240 Troubleshooting Problem Possible Cause - Solution I am sliding my finger up There are different TouchPad versions available on this computer, and this version requires and down on the right tapping/holding to scroll. Either tap repeatedly, or hold the finger down, at the top or bottom right side of the TouchPad to of the touchpad (depending on the scrolling direction required) to scroll the window.
Page 241 Troubleshooting Problem Possible Cause - Solution When a DVD is played in This is an issue with Windows Media Player/Media Center and audio output through the S/PDIF- Windows Media Player/ Out Jack. We recommend that you use the Power DVD application to play DVDs. Media Center, the audio track in other languages (commentaries etc.) is...
Page 242 Troubleshooting Problem Possible Cause - Solution have installed The audio driver is not installed. Install all the drivers as instructed in Chapter 4 "Drivers & Windows operating Utilities" and make sure you install the audio driver (see “Audio” on page 4 - system but cannot hear any sound.
Page 243 Troubleshooting Problem Possible Cause - Solution The computer is off (or in The port is not powered on. Toggle power to the port using the Fn + power button combination. Sleep Mode) powered by the AC/DC This function may not work with certain external USB compliant devices (check your device’s doc- adapter plugged in to a umentation).
Page 244 Troubleshooting Problem Possible Cause - Solution When the battery is being This can occur as the battery cell performs poorly in a low temperature environment, especially used to power the system with a discharge rate of over 2C. Systems powered by the battery will perform normally at ...
Page 245 Troubleshooting Problem Possible Cause - Solution The Bluetooth module There is a conflict between an existing Bluetooth module and a Bluetooth & WLAN combination experiencing module. You should have only one Bluetooth module installed in order to prevent any problems/ 2 Bluetooth conflicts (this includes the Bluetooth element of any combination WLAN &...
Page 246 Troubleshooting Problem Possible Cause - Solution Note that after installing By default, Intel® Rapid Storage Technology is set to Automatic (Delayed Start). If you want IRST driver to change the setting then follow these steps to change the Startup type: Windows system Go to Intel®...
Page 247: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 248 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 249 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 250 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 20 Bluetooth Connection Problems...
Page 251: Intel® Centrino Advanced Wlan & Bluetooth V3.0+Hs Combo Modules
Troubleshooting Intel® Centrino Advanced WLAN & Bluetooth V3.0+HS Combo Modules Note that, at the time of going to press, Intel® Centrino® Advanced-N 6230 WLAN & Bluetooth V3.0+HS combo modules use the standard Bluetooth configuration in Windows 7 (see “Standard Bluetooth Configura- tion in Windows 7”...
Page 252 Troubleshooting 8 - 22...
Page 253: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 254: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) / RSMMC SD (Secure Digital) / Mini SD / SDHC / SDXC MS (Memory Stick) / MS Pro / MS Duo Push the card into the slot and it will appear as a removable device.
Page 255: Hdmi-Out Port
Interface (Ports & Jacks) Item Description e-SATA/Powered USB This is a combined e-SATA (external Serial Advanced Technology Attachment)/ USB 3.0 3.0 Port compatible port. Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology Attachment) port. *See “USB 2.0/1.1 Ports*”...
Page 256: Line-In Jack
Interface (Ports & Jacks) Item Description Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers. Note that audio input through Line-in will default to the mute setting. To set up your audio sources to play through the Line-in jack go to the Sound control panel and make sure the Mute box is not ticked.
Page 257: Security Lock Slot
Interface (Ports & Jacks) Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. USB 2.0/1.1 Ports* These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
Page 258 Interface (Ports & Jacks) A - 6...
Page 259: Control Center
Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
Page 260 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the power status of modules (e.g. WLAN, Bluetooth, 3G or Camera), screen brightness, TouchPad power and Silent Mode.
Page 261 Control Center User Modes Power Saving Flight Entertainment Quiet Performance Defined Icon Power Plan Power Saving Balanced Power Saving Power Saving High Performance Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance Brightness WLAN Bluetooth BIOS Defined PC Camera TouchPad Table B - 1- Power Modes...
Page 262 Control Center Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
Page 263 Control Center Sleep Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer enter the appropriate power-saving mode (see “Power-Saving States” on page 3 - 6). Click in a blank area of the icon or press a key on the keyboard to exit Power Conservation Mode without making any changes Display Switch Click the Display Switch button to access the menu (or use the...
Page 264 Control Center Caps Lock/Scroll Lock/ Number Lock Click the button to toggle the appropriate lock mode. B - 6 Control Center...
Page 265: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix C: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - Video Card Options NVIDIA Video Driver Installation Note that card types, Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - specifications and driv- ers are subject to contin-...
Page 266: C - 2 Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel  More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Click Start, and click Control Panel (or point to Settings and click Control Panel). To access the Ge- Double-click NVIDIA Control Panel (click "Classic View"...
Page 267 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and  tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 268 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure C - 3 Help Menu C - 4 NVIDIA Control Panel...
Page 269: Display Devices
NVIDIA Video Driver Controls Display Devices  Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI Display Devices (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use a Besides the built-in LCD, you can also use an exter- converter to convert the signal from DVI to VGA).
Page 270: Display Modes
NVIDIA Video Driver Controls Display Modes  Single Display Mode SLI Configuration & Only one of your displays is used. Multiple Displays Note that if SLI configu- Duplicate Displays ration is enabled only a Duplicate simply shows an exact copy of the Primary display desktop on the other Single display may be display(s).
Page 271: Configuring An External Display (Nvidia
NVIDIA Video Driver Controls Configuring an External Display (NVIDIA)  You can use the NVIDIA control panel to configure any attached displays. Display Not Shown Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see page If the attached display Double-click Display (if the sub-menus are not visible), and then click Set up...
Page 272: Duplicating The Displays
NVIDIA Video Driver Controls Duplicating the Displays Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see page Double-click Display (if the sub-menus are not visible), and then click Set up multiple displays.
Page 273: Extending The Display
NVIDIA Video Driver Controls Extending the Display  Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see page Changing the Double-click Display (if the sub-menus are not visible), and then click Set up Primary Display on multiple displays.
Page 274: Changing The Primary Display On Extended Displays
NVIDIA Video Driver Controls Changing the Primary Display on Extended Displays If you want to switch the primary display if the displays are extended then right- click the secondary display icon. Select Make this the Windows main display. Click Apply > Yes to save the change. Figure C - 7 Switch Primary Display...
Page 275: Attaching Other Displays (Win 7
NVIDIA Video Driver Controls Attaching Other Displays (Win 7)  Configuring an External Display in Windows 7 Function Key Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Combination Go to the Screen resolution control panel. You can use the Fn + F7 Click the Detect button.
Page 276 NVIDIA Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 9 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 277: Using The Windows Logo Key + P Key Combination To Switch Displays
NVIDIA Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your external display to the external monitor port and turn it on.
Page 278: Sli Multi Gpu Configuration
NVIDIA Video Driver Controls SLI Multi GPU Configuration  This computer features an NVIDIA Scalable Link Interface (SLI) that improves Video Card graphic quality and performance by combining dual NVIDIA GPUs (two video Options cards are required) in a single system. To enable/disable SLI Configuration: Note that card types, Go to NVIDIA Control Panel (see page specifications and driv-...
Page 279: Sli Multi Gpu Configuration & Power
NVIDIA Video Driver Controls SLI Multi GPU Configuration & Power  Note that due to the high power and system demands created by enabling an SLI SLI Configuration & configuration, you should not power the system using the battery only and you Multiple Displays will require identical (300W) dual power adapters, connected to a power con- verter box, to power the system.
Page 280: Manage 3D Settings
NVIDIA Video Driver Controls Manage 3D Settings You can configure the 3D global settings (to be applied to all application programs) or make specific adjustments for installed program settings. Go to NVIDIA Control Panel (see page Click Manage 3D Settings and select either Global Settings or Program Settings. Click the Setting menu items to select any global options required, or select a program to customize from the drop-down menu (click Add to add any program that does not appear in the menu).
Page 281: Adjust Video Settings
NVIDIA Video Driver Controls Adjust Video Settings You can adjust video color and image settings from the Video sub-menus. Go to NVIDIA Control Panel (see page Click “+” next to Video if its sub-items are not shown and then click either Adjust video color settings or Adjust video image settings.
Page 282: Hdmi Audio Configuration
NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you can configure the audio output from the NVIDIA control panel and Sound control panel. The settings will depend upon the external HDMI display you have connected to.
Page 283: Audio Setup For Hdmi
NVIDIA Video Driver Controls Audio Setup for HDMI In some cases it will be necessary to go to the Sound control panel and manually con- figure the HDMI audio output. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 284 NVIDIA Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 17 HDMI Device Properties C - 20 HDMI Audio Configuration...
Page 285: Hdmi Notes
NVIDIA Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • Under certain conditions, if the HDMI cable is disconnected, the default audio If you are using a third playback device will not revert to speakers until the computer is restarted (if you party application to play...
Page 286: Hdcp Status
NVIDIA Video Driver Controls HDCP Status If your external display is HDCP (High Bandwith Digital Content protection) com- patible then the NVIDIA control panel will display the HDCP system status. Figure C - 18 HDCP Status C - 22 HDMI Audio Configuration...
Page 287: Nvidia 3D Shutter Glasses Kit
NVIDIA Video Driver Controls NVIDIA 3D Shutter Glasses Kit  The NVIDIA 3DVISION™ 2 shutter glasses kit is supported only by Model B NVIDIA Driver computers which include the built-in 3D emitter and shutter glasses kit. Install the video driver as indicated in “Video (VGA)”...
Page 288: Stereoscopic 3D Hardware Setup
NVIDIA Video Driver Controls Stereoscopic 3D Hardware Setup If your computer model features a built-in 3D IR emitter the loa ct ion is illustrat- ed below. The effective viewing angles of the emitter are illustrated overleaf. Make sure that you are viewing the notebook screen within the area highlighted overleaf in order to get the proper stereoscopic 3D effect.
Page 289: Viewing Angles
NVIDIA Video Driver Controls Viewing Angles The emitter’s horizontal viewing angle is 100 degrees. The emitter’s vertical viewing angle is 75 degrees. Figure C - 20 Emitter - Viewing Angles 75 NVIDIA 3D Shutter Glasses Kit C - 25...
Page 290: Set Up Stereoscopic 3D
NVIDIA Video Driver Controls Set Up Stereoscopic 3D  Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click NVIDIA Control Panel (click "Classic View" from the left of the Enable 3D Vision menu if you are in Control Panel Home). You can enable 3D Vi- Double-click Stereoscopic 3D (if the sub-menus are not visible), and then click sion if the NVIDIA con-...
Page 291 NVIDIA Video Driver Controls Select the drop-down menu at the bottom of the screen to Test stereoscopic 3D. Select Run Setup Wizard from the drop-down menu (you can also select Run Medical Image Test from this menu). Follow the on-screen instructions to set up 3D Vision and click “Next” to progress through the steps (this notebook has a built-in emitter).
Page 292 NVIDIA Video Driver Controls 11. The stereoscopic depth may be adjusted by using the control panel slider. 12. Click View Compatibility With Games to check 3D support for any games. Figure C - 23 Compatibility With Games C - 28 NVIDIA 3D Shutter Glasses Kit...
Page 293: Specifications
Specifications Appendix D: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 294: Processor
Specifications Processor Memory  Intel® Core i7-3960X (3.30GHz) Four Channel DDRIII (DDR3) 15MB L3 Cache, 32nm (32 Nanometer), Four 204 Pin SO-DIMM Sockets SLI Multi GPU Configuration DDR3-1600MHz, TDP 130W Supporting DDRIII (DDR3) 1333/1600 & Power MHz Memory Modules (real operational Intel®...
Page 295: Bios
Specifications BIOS Keyboard & Pointing Device Slots One 64Mb SPI Flash ROM Full Size Winkey Illuminated Keyboard One ExpressCard™ (34/54) Slot with Numeric Keypad AMI BIOS One Mini Card Slot for WLAN & Bluetooth Storage Built-In TouchPad (with Multi Gesture Combo Half Mini-Card Module with PCIe Functionality) &...
Page 296: Communication
Specifications Communication Security Environmental Spec Built-In 10/100/100 Base-TX Ethernet LAN Security (Kensington® Type) Lock Slot Temperature ° ° BIOS Password Operating: C - 35 Intel® Centrino® Ultimate-N 6300 3*3 Fingerprint Reader Module Non-Operating: -20°C - 60°C (802.11 a/g/n) Half Mini-Card PCIe WLAN Trusted Platform Module 1.2 Relative Humidity Module (Factory Option)
