System Map: Right View

1
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) / MS Pro
3 3 3 4
2
4-in-1 Card Reader
(Memory Stick Pro)
1.
2.
5
6 7
3.
4.
5.
6.
7.
*
Tuner Only
System Map: Right View 1 - 11
Quick Start Guide
Figure 1 - 6 - Right View
PC Card Slot
Mini-IEEE 1394a Port
3 * USB 2.0 Ports
TV Antenna Jack*
4-in-1 Card Reader
Infrared Transceiver
(see page 2 - 12)
RJ-45 LAN Jack
Enabled with Optional Mini-PCI TV
Mini-IEEE 1394a
The Mini-IEEE 1394a
port only supports SELF
POWERED IEEE 1394a
devices.
