Modules
Figure 7 - 2
MediaShield ROM
BIOS Startup
7
Figure 7 - 3
MediaShield BIOS
Define A New Array
7 - 6 RAID Setup
7. As the computer boots up you will see the screen below if no disk array is defined
(press F10 to enter the utility).
MediaShield ROM BIOS 10.0.0.31
Copyright (C) 2008 NVIDIA Corp.
Detecting storage devices...
1 0.1 TSSTcorp CDDVDW TS-L633A
Press F10 to enter RAID setup utility ...
8. The MediaShield ROM BIOS Utility will then appear (if you have not previously
set up an array then you will be presented with the "Define a New Array" menu).
RAID Mode : Mirrored
Free Disks
Port Disk Model
0.0 FUJITSU MHY212 111.79GB
0.2 FUJITSU MHZ225 232.88GB
[ ESC] Quit
[F6] Back
MediaShield BIOS Mar 31 2008
- Define a New Array -
Striping Block:
Array Disks
Capacity Port Disk Model
[ ] Add
[ ] Del
[F7] Finish [TAB] Navigate [
Optimal
Capacity
] Select [ENTER] Popup
