Quick Start Guide
1

System Map: Right View

1
The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats.
The card reader allows you to use the most popular digital storage card formats:
MS Duo (requires PC adapter) / Mini SD (requires PC adapter) /
1 - 14 System Map: Right View
3
2
ExpressCard Slot
7-in-1 Card Reader
MMC (MultiMedia Card) / SD (Secure Digital) /
MS (Memory Stick) / MS Pro (Memory Stick Pro)
RS MMC (requires PC adapter)
3
4
5
6
Figure 1 - 6 - Right View
1. ExpressCard Slot
(see page 2 - 7)
2. 7-in-1 Card Reader
3. 2 * USB 2.0 Ports
4. RJ-45 LAN Jack
5. 7-Pin S-Video-Out
Jack
6. External Monitor Port
