System Map: Right View - EUROCOM Notebook User Manual

System Map: Right View

3
1
2
Changing DVD Regional Codes
Go to the Control Panel and double-click System >
Hardware (tab), click Device Manager, then click
the + next to DVD/CD-ROM drives. Double-click on
the DVD-ROM device to bring up the Properties di-
alogue box, and select the DVD Region (tab) to
bring up the control panel to allow you to adjust the
regional code (see "DVD Regional Codes" on
page 2 - 5).
DVD region detection is device dependent, not OS-
dependent. You can select your module's region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
4
5
If you need to manually eject a CD/DVD (e.g. due to an unexpected
power interruption) you may push the end of a straightened paper clip
into the emergency eject hole. Do not use a sharpened pencil or similar
object that may break and become lodged in the hole.
Don't try to remove a floppy disk/CD/DVD while the system is access-
ing it. This may cause the system to "crash".
Quick Start Guide
Figure 1 - 6 - Right View
1. Headphone-Out/Speaker-Out
Jack
2. Microphone-In Jack
3. 2 * USB 2.0 Ports
4. Optical (CD/DVD) Device Drive
Bay
5. Security Lock Slot
CD Emergency Eject
Media Warning
System Map: Right View 1 - 11
1
