System Map: Left View

1
2
The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Make sure
you install the IEEE 1394 filter driver (see page
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick)
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter)
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
Note that the HDMI-Out Port supports video and audio signals to attached external displays
(also see "HDMI Audio Configuration" on page B -
5
3
4
8
Mini-IEEE 1394 Port
4 - 7).
7-in-1 Card Reader
HDMI-Out Port
8).
6
7
System Map: Left View 1 - 13
Quick Start Guide
Figure 1 - 7
Left View
1. DVI-Out Port
2. 2 * USB 2.0 Ports
3. RJ-45 LAN Jack
4. HDMI-Out Port
5. 7-in-1 Card Reader
6. ExpressCard Slot
7. Mini-IEEE 1394 Port
8. Optional Device
Drive Bay
See Appendix A for a more
detailed description of the
ports & jacks etc.
USB Ports
Note that the connec-
tions to the USB ports
only fit one way, do not
force them.
1
