EUROCOM Notebook V09.1.00 User Manual page 114

Upgrading The Computer
Caution
The heat sink, and video
card area in general,
contains parts which are
subject to high tempera-
tures. Allow the area
time to cool before re-
moving these parts.
6
Figure 6 - 18
Heatsink Removal
6 - 16 Upgrading the Video Card
7. Remove screws -
13
(two video cards are pictured here).
8. Grip the handle and carefully remove the heatsink
17
9. Remove screws -
19
14 16
15 13
17
from the heatsink in the order indicated on the label
16
from the video card.
21
14 16
15 13
17
20
.
18
18 18
20
21 21
19 19
